Montage Sensor + Magnet /
Mounting sensor + magnet
MONTAGEANLEITUNG / INSTALLATION INSTRUCTIONS
Type A
Option A
Option B
Type B
Die Sensorkontrollleuchte
signalisiert den korrekten
Abstand zum Magneten.
The sensor indicator light
signals the correct
distance to the magnet.
Achtung: Montieren Sie
den Sensor auf der Vor-
derseite der Gabel.
Attention: Mount the
sensor on the front side
of the fork.
