Cuisinart CPT-200 - Step 12: Install Tool Hooks; Step 13: Connect Frame to Top Assembly

A
x16
9
ASSEMBLY INSTRUCTIONS
STEP 12
--------------------------------------------------------------------------------------
• Attach the tool hooks (13) using 6 C screws and 6 E washers as shown below.
STEP 13
--------------------------------------------------------------------------------------
• Lift the frame on to the counter top assembly and line up the holes on the legs with the holes on the
counter top assembly as shown below. Use 4 A screws on each leg to secure.
C
x 6
E
x 6
Note: Make sure left front
leg is in the correct position
during this step.
!
