Cunill tranquilo - Page 12

(nº12) MICHIGAN Model
H:700mm L:355mm W:210mm Wei: 18Kg
Number of motors: 1
Voltage:230v-110v-Frequency:50Hz-60Hz
Phases: 1(single)-Amperage: 3,1A - 6,82A
Power: 0,50/680
Condenser: 20nf-450v -80nf-400v
Speed:1300-1650 - Protection degree: IP21.
Motor equipped with Thermal Protector
Tempered Steel Grinding Wheels, 65mm.
Duration of Grinding Wheels:500kg Cof.B.
Hopper Capacity: 2 Kg.
Dispenser Capacity: Bags
Dispenser adjustment: NO.
Special Bags filling.
-Manual.models:3minutes working, 15 minu-
tes stop.
(nº12) MOVIE - “Silencer” Model
Al:660mm L:460mm W:265mm Wei: 18Kg
Number of motors: 1 (op) + 1motor-fan
Voltage: 230v-110v-Frequency: 50Hz-60Hz
Phases: 1(mono)-Amperage: 2,1A - 4,62A
Power:0,30/360
Condenser: 14nf-450v -55nf-400v
Speed:1300-1650. Protection degree: IP21
Maximum Continuous Service Time:30min.
Motor equipped with Thermal Protector
Tempered Steel Grinding Wheels, 65mm
Duration of Grinding Wheels:500kg
Cof.B.Capacidad tolva: 2 Kg.
Hopper Capacity: 600 Gr.
Dispenser adjustment: 5Gr - 12Gr.
On-Off: Automatic(Movie)
On-Off:Automatic every 8 coffees-Bi.motor
-Manual.models:3minutes working, 15 minu-
tes stop.
07 Technical Specifications
