1 Hopper lid.
2 Hopper.
4 Split pin (opening/closing) of the hopper.
5 Adjustment pawl.
6 Selection-lever of adjustment.
7 Holding lever for the bags
8 Vibrating Stainless Steel plate.
9 On / Off switch.
10 Air exits.
08 Components Identification (Classic)
1
2
4
3
5
7
8
9
10
12
14
6
13
11
1
2
4
5
6
7
8
9
10
1. Coffee bean hopper lid.
2. Coffee bean hopper
3. Fixing anchors
4. Grinder Adjustment platen
5. Trap of (open/close) bean hopper.
6. Adjustment pawl.
7. Ground coffee dispenser lid.
8. Ground coffee dispenser.
9. Ground coffee adjustment screw.
10. Ground coffee press..
11. On / Off switch.
12. Direct intake (seal-saver).
13. Coffee collection Tray.
14. Dosing lever
