REPLACEMENT PARTS LIST
CURRENTBACKYARD.COM8
Key Qty Description
1 1 TOP LID
2 1 HANDLE F/ LID
3 2 TOP LID RUBBER BUMPER
4 1 LOGO PLATE F/ LID
5 2 TOP LID HINGE
6 1 FIREBOX FRAME
7 1 ELEMENT TRAY BOTTOM
8 8 ELEMENT TRAY SUPPORT PIN
9 1 POWER BOX MODULE
10 2 ELEMENT TRAY
11 4 GREASE TENT
12 2 HEATING ELEMENT
13 1
TEMPERATURE SENSOR
(WHITE)
14 1 TEMPERATURE SENSOR (RED)
15 2 BRACKET, F/ WARMING RACK
16 1 CONTROL PANEL HOUSING
17 1 CONTROL MODULE
18 1 CONTROL MODULE PANEL
19 1
PROBE JACK, SET OF
(WHITE)
20 1
PROBE JACK, SET OF
(RED)
21 1 CONTROL KNOB
22 2 GREASE TRAY BRACKET
23 1 GREASE PAN
24 1 WARMING RACK
25 4 COOKING GRATE
26 1
SHELF GROMMET (SET OF )
27 1 LEFT SIDE SHELF
28 1 RIGHT SIDE SHELF
29 2 END CAP, F/ SIDE SHELF
30 1 LEFT FRONT LEG (#1)
31 1 LEFT REAR LEG (#2)
32 1 RIGHT FRONT LEG (#3)
33 1 RIGHT REAR LEG (#4)
Key Qty Description
34 2 LEG CAP, FRONT
35 2 LEG CAP, REAR
36 2 SIDE CART BRACE
37 2 WHEEL
38 1 WHEEL AXLE (SET OF )
39 1 MIDDLE CART SHELF
40* 2 SIDE CART PANEL
41* 1 REAR CART PANEL
42* 2 FRONT/ REAR BRACE
43* 1 DOOR, NO HANDLE
44* 1 HANDLE F/ DOOR
45 1 CORD WRAP
46 1 BOTTOM SHELF
47 2 CASTER, LOCKING
48 1
OUTSIDE MEAT PROBE
HOLDER
49 2 MEAT PROBE
50 1
POWER CORD REPLACE-
MENT
51* 1 MAGNET ASSEMBLY
52* 1 FIXED PIN, F/ DOOR
53* 1 SPRING PIN, F/ DOOR
54 1 TRAY, PERFORATED
55 1 TRAY, SOLID
56* 6 PANEL CLIP
57 1 GROMMET, SMOKE SHOT
58 1 GROMMET, POWER CORD
NOT Shown
… 1 PRODUCT GUIDE
… 1 HARDWARE PACK
… 1
CART/SHELF HARDWARE
REPLACEMENT
*
NOT INCLUDED IN CART MODELS
