INSTALLATION
9
3. Remove the top left screw cover.
4. Move the core cover from left side to
right side. And then lift the door and
place it on a padded surface to prevent it
from scratching.
5. Remove the screws and bottom hinge.
Then remove the adjustable feet from
both side.
Unscrew
