CONTROL REFERENCE GUIDE
BACK VIEW
32
FRONT VIEW
1.Color LCD Screen
2.Remote Sensor
Do not block this sensor or the
remote control will not work.
3.Standby Indicator
Indicates whether the unit is ON
or in STANDBY (OFF) mode.
Light in red: The unit is in STANDBY.
Light in green:The unit is turned ON.
4. Speakers
1.TV ANTENNA Terminal
2.HEAD PHONE Jack
3.AUDIO IN Jack (Right)
4.AUDIO IN Jack (Left)
5.VIDEO IN Jack
6.S-VIDEO Jack
7.Y / PB / PR Jacks
8.PC AUDIOIN Jack
9.VGA IN Jack
10.HDMI IN Jack
