AC/DC MODELS AC/DC MODELS DC-ONLY MODELS
(AC Operation) (DC Operation)
Input Voltage 20 to 264 V ac, 50/60 Hz 15 to 30 V dc 10 to 30 V dc
(15 to 24 V dc above 55° C/131° F) (10 to 24 V dc above 55°C/131° F)
Power Dissipation 1.5 W maximum 1.5 W maximum 1 W maximum
Output Type VMOS (bi-directional) NPN (sink) NPN and PNP (dual outputs)
Current Switching 300 mA maximum 300 mA maximum PNP (source): 100 mA maximum;
Capacity NPN (sink): 250 mA max.
(120 mA max. above 55° C/131° F)
Voltage Switching 375 V peak maximum 375 V peak maximum 30 VDC maximum
Capacity
Off-State Leakage 250 µA typical 250 µA typical 10 µA maximum
500 µA maximum 500 µA maximum
Surge Current 2 A maximum 2 A maximum 1 A maximum
On-State Voltage - - - 1.8 V at 10 mA; 3.5 V at 300 mA NPN: 400 mV at 10 mA,
Drop 1.5 V at 250 mA;
PNP: 2.8 V at 100 mA
Response Time 8 mS 3.5 mS
Short Circuit Sensor will turn off immediately when a short or overload is detected (Indicator LED will flash).
Protection Turn power OFF and back ON to reset.
IMPORTANT: During installation, correct power connections must be made first to ensure fail-safe short
circuit protection of the outputs.
Light/Dark Operation Switch selectable on detector
Temperature Range Operating and Storage; Source: -20° to +70° C (-4° to +158° F); Detector: -40° to +70° C (-40° to +158° F)
Material of Lens: Polycarbonate; Cable jacket: PVC; Body: Structural polyurethane foam
Construction (do not expose to concentrated acids, alcohols, or ketones)
Cable/Connector 6-foot cable, 3-wire (ac/dc models), 4-wire (dc-only models); Micro Connector, 4-pin male
Vibration and Shock Vibration: 30 g over 10 Hz to 2 kHz; Shock: 100 g for 3 mS 1/2 sinewave pulse
Indicator LED Source: Lights when power is ON; Detector: Lights steady when output is ON, Flashes when short circuit
protection is in latch condition
Sunlight Immunity 10,000 foot-candles
Enclosure Ratings NEMA 1, 2, 3, 4, 4X, 6, 12, and 13
(Our products conform to NEMA tests as indicated, however, some severe washdown applications can
exceed these NEMA test specifications.If you have questions about a specific application, contact our
Applications Department.)
Approvals Contact factory for the latest list of approvals
SPECIFICATIONS
