Parts List
Page C-3
Cybex 750C/750R Owner’s Manual
ITEM QTY PART NO. DESCRIPTION
1 1 AD-21280 PCA,LOWER CONTROLLER
2 1 AF-21040 WELDMENT,FRAME,750R
3 1 AF-21506 WELDMENT,LEVELER WELDNUT
8 1 AX-21327 ASSY,IDLER ARM,750C 750R
9 1 AX-21387 ASSY,SEAT SHUTTLE EXTR.
10 1 AX-21670 ASSY,SEAT BACK,750R
11 1 AX-21683 ASSY,BRAKE SHIELD IDLER,750R
12 2 AX-21732 ASSY,WHEEL,750C 750R
13 1 AX-62023 ASSY,LEFT CRANK BEARING
14 1 AX-62031 ASSY,RIGHT CRANK BEARING
15 1 BD-21366 BELT,POLY-V,480J8(1222 PJ8)
16 4 HX-20360 INSERT,EXPANSION
17 1 PL-20218 DUCT,FAN,RIGHT
18 1 PL-20340 DUCT,FAN,LEFT
19 1 PL-20948 CONSOLE,SMALL,FRONT
20 1 PL-20949 CONSOLE,SMALL,BACK
23 1 EC-21351 BATTERY,12V/1.2AHR
24 2 EH-00472 CABLE TIE,3.9IN
25 2 EH-00986 TY WRAP,T B TYB-25M 9 IN
26 3 EH-10291 TY WRAP BASE
27 1 FM-19470 CRANK,RIGHT ARM
28 1 FM-19471 CRANK,LEFT ARM
29 1 FM-19472 SHAFT,530C R,CRANK
30 1 FS-21511 CLAMP,BATTERY,750R
31 16 HS-15706 SCREW,8-16X.50,PNHD
32 2 HN-00199 NUT 3-8-16 HEX STL ZINC
33 1 HN-41157 NUT,7-8-24,LH,86A,ZN
34 3 HS-11977 SCREW SEMS,8-32X.38,PNHD
36 8 HS-16875 BOLT SEMS,1-4-20X.5,PNHD
37 4 HS-19108 SCREW 5-16-18X3-4LG,HXHD
39 4 HS-18294 SCREW,SEMS,10-32X.38
40 4 HS-18497 SCREW,10-32X .50,PNHD
41 2 HS-19467 BOLT,M8X1X20,SCHD BTN BTN
42 2 HS-19468 BOLT,M8X1X22,SCHD CAP
43 4 HS-21612 SCREW,10-32X7-16,SCHD CAP,SS
45 4 HS-41109 SCREW SLFTP,10-24X.75,PNHD
46 6 HS-41126 BOLT,5-16X1.0,BTHD,SST,BLK
47 4 HW-21878 WASHER SAE NO.10 STL ZINC
48 1 HW-18176 WASHER,CRANK KEY
49 2 HW-19469 WASHER,FLAT 17.2 X 21.5 X .75
50 1 HX-19529 GRIP RING RETAINING 3-8 IN
51 14 HX-20360 INSERT,EXPANSION,PLASTIC
52 1 HX-21374 SPRING,EXTENSION
53 3 HX-21519 PIN,PLASTIC RETAINIER
54 1 HX-21603 TAPE, DBL SIDED
55 1 PL-18132G END CAP,SEAT SHUTTLE,GRAY
56 1 PL-21486 SHROUD,SHUTTLE,LEFT
57 1 PL-21487 SHROUD,SHUTTLE,RIGHT
58 1 PL-21515 SHROUD,FRONT LEFT,750R
59 1 PL-21516 SHROUD,FRONT RIGHT,750R
60 1 PL-21517 CAP,TOP LEFT,750R
61 1 AX-21855 CAP,TOP RIGHT,750R, W/PINS
62 2 HX-22203 LEVELER, 3/8-16”, RUBBER
63 1 PW-20877 PULLEY,PRIMARY,750C 750R
66 4 HS-41006 SCREW SLFTP,10-24X.5,PNHD
67 1 PL-50118 CLAMP,CABLE CT
70 4 HS-41107 BOLT,5-16-18X1.5,BTHD,SST,BLK
71 1 AD-21192 PCA,DISPLAY,750C 750R 750A
72 1 AD-21195 PCA,MCC,PROGRAMMED
73 1 AF-21332 PLATE,MOUNTING
74 8 HW-53018 WASHER 5-16 SPLIT SS,BLK
78 1 EC-19706 FAN,12VDC,120X120MM,CFM30
79 1 EC-21472 PCA,POLAR,SENSOR
Parts List Cybex 750R Cybex
ITEM QTY PART NO. DESCRIPTION
81 1 DE-20364 DIFFUSER, .60 OD DISC
82 2 HS-18311 SCREW,8-16X.75,PNHD PHIL
83 2 HS-20367 SCREW SEMS,M4X10MM,PNHD
84 3 HS-20399 SCREW SEMS,8-32X1.25,PNHD
85 12 HS-41187 SCREW SLFTP,8-16X.3125
91 1 FS-21599 COVER,LOWER CONTROLLER
92 0 TR-21265 POWER SUPPLY
93 0 EH-42713 CABLE TIE 11IN
121 1 AF-18000 WELDMENT,SHUTTLE HANDLE
122 1 AF-21385 WELDMENT,SEAT SHUTTLE 750R
124 4 AX-18148 ASSY,SEAT SHUTTLE WHEEL
125 2 AX-19669G GRIP,HR TOP,IN-MOLDED,GRAY
126 2 AX-19670G GRIP,HR BTM,IN-MOLDED,GRAY
129 2 CW-18141 WHEEL,LOWER RIGHT,TAPERED
130 2 CW-18144 WHEEL,LOWER LEFT,BEVELED
131 4 FM-18143 SPACER,LOWER SHUTTLE WHEEL
132 4 FS-18023 PLATE,WHEEL TENSION ADJ.
133 2 HB-18121 BUSHING FLANGED,PLASTIC
134 2 HN-11925 KEPS,10-32 HEX STL ZN
135 4 HN-18252 NUT,5-16-18,PREVAILING TORQUE
136 1 HN-60558 NUT NYLOC .250-20 ZN,BLK
138 1 HS-18089 BOLT,SHLD,5-16X2.75 SCHD
139 4 HS-18298 BOLT,5-16-18X .88,BTHD CAP
140 8 HS-18358 BOLT,5-16-18X.1.25,SCHD CAP
141 2 HS-18497 SCREW,10-32X .50,PNHD PHIL
142 4 HS-20306 SCREW,6-20X1.12 PNHD PHIL
143 8 HW-18123 WSHR,.344IDX.75 ODX.125
144 4 HW-53018 WASHER 5-16 SPLIT SS,BLK
145 1 HX-18168 SPRING,TORSION,SEAT SHUTTLE
146 1 PD-18166G SEAT BOTTOM,750R,GRAY
147 1 PL-18204 CLAMP,FLAT CABLE COVER
148 2 PL-20230G END CAP, CONTACT GRIP,GRAY
149 1 PL-21655 ACCESSORY TRAY TOP,750R
150 1 PL-21656 ACCESSORY TRAY BTM,LEFT
151 1 PL-21657 ACCESSORY TRAY BTM,RIGHT
200 1 AC-21737 CONSOLE ASSY,750R
201 1 AD-20840 PCA,PEM JACK BOARD
202 1 AF-21408 BRKT,AV,LOWER
207 1 AX-21738 ASSY,IPOD TRAY
209 1 DE-18362-X* DECAL,CAUTION MOVING PARTS
210 1 DE-18363-X* LABEL,WARNING HOT FLYWHEEL
211 1 DE-21241-X* MASK,ENUNCIATOR,750C 750R
212 1 DE-21243-X* DECAL,750C 750R CONSOLE TOP
213 1 DE-21590-X* LABEL,WARNING,IPOD HOLDER
218 1 PL-20950 CONSOLE,SMALL,TOP
218 1 PL-20951 CONSOLE,SMALL,TOP,A/V
219 1 KAD-21926 COVER,BOTTOM,AV
219 1 PL-21292 COVER,BOTTOM,NON-AV
221 1 DE-21689 DECAL,750R AV BLANK
221 1 SW-20813-X* MEMBRANE,AV KEYPAD
223 1 DE-21749-X* DECAL,DISCONNECT POWER
224 1 DE-21763 DECAL,ETL CSA
225 1 SW-21242-X* MEMBRANE,BOTTOM
226 1 DE-21735-4 DECAL, ERROR CODE, WARNING
300 1 AX-21382 PEDAL,9-16 THREAD,LEFT
301 1 AX-21383 PEDAL,9-16 THREAD,RIGHT
302 1 AX-21384 ASSY,SEAT SHUTTLE,750R
303 1 AX-21740 ASSY,CONSOLE WELDMENT,750R
304 2 HX-21329 GRIP,HANDRAIL,750R
400 1 AF-20959 WELDMENT,AV MOUNT
401 1 CP-21072 MONITOR, ATSC DIGITAL PEM
401 1 CP-21073 MONITOR, DVB-T DIGITAL PEM
To Next Page
