Cybex VR3 12160 Lat Raise Owner’s Manual
Service
Page 6-4
ITEM QTY PART NO. DESCRIPTION
1 3 11040-301 CLAMP BLOCK INSERT
2 1 11040-440 KNOB
3 2 11070-332 COUNTERWEIGHT
4 2 11090-374 END CAP
5 2 11090-376 RING, HANDLE GRIP
6 1 11130-330 DECAL SHOULDER HEIGHT
7 2 11160-316 PLATE PULLEY MOUNTING
8 1 11160-344 PLATE, GUARD
9 1 12000-339 PIN, DETENT
10 1 12000-342 PIN, DETENT
11 1 12000-344 INSERT, PLASTIC
12 1 12000-345 FOOT PAD, 4.00 x 7.00
13 1 12000-466 PULLEY COVER
14 1 12000-392 CHANNEL, INCREMENT WEIGHT
15 1 12000-394 CHANNEL, INCREMENT WEIGHT
16 1 12000-395 TOP CAP
17 2 12000-396 END CAP
18 4 12000-398 SPACER
19 1 12000-413 PANEL INSERT
20 2 12050-343 WASHER
21 4 12050-346 WHEEL, PLASTIC ROLLER
22 1 12050-348 GUIDE, ROLLER
23 1 12160-331 LINK BAR
24 1 12070-329 DECAL, ADJUSTING
25 1 12070-394 DECAL, INDICATOR
26 4 12090-322 FOOT PAD
27 6 12100-303 BUMPER
28 1 12160-200 MAIN FRAME
29 1 12160-201 CAM RH
30 1 12160-202 CAM LH
31 1 12160-203 INPUT ARM RH
32 1 12160-204 INPUT ARM LH
33 1 12160-208 SEAT BOTTOM
34 1 12160-328 PLATE, GUARD
35 1 12160-999 * OWNER’S MANUAL
36 1
12190-208 DETENT BAR
37 1 12190-354 GAS SPRING MOUNT
38 2 12210-347 GUIDE ROD CAP
39 2 12210-348 GUIDE ROD CAP
40 2 12210-350 WT ROD .625 DIA X 49.53
41 2 4000Y316 * DECAL, CAUTION
42 1 4520-362* DECAL, CAUTION
43 1 4530-203 HANDLE LH
44 1 4530-204 HANDLE RH
45 1 4605-381 * WARNING LABEL
46 1 4715-346 COMPRESSION SPRING .72 x 1.50 LG
47 1 51198 WARRANTY BOOK (NOT SHOWN)
48 1 8500-026* DECAL, CAUTION
ITEM QTY PART NO. DESCRIPTION
49 4 BR030210 RETAINING RING, 17mm
50 2 BS070208 COMPRESSION SPRING
51 1 CM000211 DECAL, PATENT PENDING
52 1 EZ000008 GAS SPRING 100N
53 4 FB030249 BEARING, RADIAL 35 MM EXT.RACE
54 4 FB130207 BRG FLG 17mm X 19mm X 25mm
55 4 FC030009 TOLERANCE RING 72MM
56A 133” GB000202 STANDARD WEIGHT STACK BELT .95 WIDE
56B 72” GB000202 BELT .95 WIDE
57 6 GP000209 PULLEY ASSEMBLY-3.50
58 2 GP000212 PULLEY ASSEMBLY-3.50
59 6 HC700417 BHSCS .375-16 X 1.00
60 6 HC700428 BHSCS .375-16 X 2.25
61 4 HC700430 BHSCS .375-16 X 2.50
62 2 HD303312 S BOLT .250 X .500 .190-10-24
63 2 HF449063 INSERT 3/4 X 1/4-20
64 12 HF579000 PANEL FASTNER, 10-24 U TYPE
65 2 HF700000 PANEL FASTNER, .375-16 , U TYPE
66 2 HH320030 KEY .313 X .313 X 2.50
67 2 HN575100 LOCKNUT .190-No 10-24
68 2 HN664900 NUT, HEX SELF-LOCKING .312-18 ZINC
69 6 HN704901 LOCKNUT, .375-16 NYLON
70 10 HT512517 TAP SC 10-24 X 1.00 TYPE WB PN HD
PHIL BLACK
71 4 HT570410 SCREW, PNH TORX 10-24 X .375, BLACK
72 12 HX570412 BHSCS, 10-24 X .50, SS
73 2 HX-60184 BALL STUD, .312 - 18 UNC x 10 mm
74 2 HX620420 BHSCS .250-20 X 1.250 SS
75 6 HY740000 SET SCREW
76 2 JC620415 BHSCS .250-20 X .75
77 2 JC620422 BHSCS .250-20 x 1.50
78 4 JC700412 BHSCS .375-16 X .50
79 2 JC700420 BHSCS .375-16 X 1.25
80 2 JC702820 SHCS .375-16 X 1.25
81 2
JC780417 BHSCS .500-13 X 1.00
82 4 JD383315 SHOULDER BOLT .500 x .75 .375-16 UNC
83 6 JS347400 LOCKWASHER, INT TOOTH .375
84 4 PP130002 INSERT, DOMED PLASTIC
85 2 PP130003 INSERT, DOMED PLASTIC
86 2 PR060005 BUMPER, WEIGHT
87 1 4605-354 GRIP 3.25” 1.38 OD X .96 ID
87A 2 4605-504 GRIP 5.0” 1.38 OD X .96 ID
88 1 12160-598* PLACARD VR3 LAT RAISE
89 1 11000-407* DECAL, INCREMENT WEIGHT
90 1 13000-402 WATER BOTTLE HOLDER MOUNT
91 1 13000-400 WATER BOTTLE HOLDER
92 1 HT552515 TAP SCREW 8-16 X .75
93 1 11040-790 DECAL, MADE IN U.S.A.
*Language Key
German -1
French-2
Spanish-3
English-4
Japanese-6
Swedish-7
Russian-8
