Cybex VR3 12050 Leg Extension Owner’s Manual
Service
Page 6-4
1 1 11040-301 CLAMP BLOCK INSERT
2 2 11040-440 KNOB
3 1 11040-560 DECAL, WEIGHT PLATE (10 - 290)
4 1 11050-400 COUNTERWEIGHT (3.87)
5 2 11090-374 END CAP
6 2 11090-376 RING, HANDLE GRIP
7 1 12000-392 CHANNEL, INCREMENT WEIGHT
8 1 12000-394 CHANNEL, INCREMENT WEIGHT
9 1 12000-395 TOP CAP
10 2 12000-396 END CAP
11 4 12000-398 SPACER
12 1 12000-406 PANEL INSERT
13 1 12050-200 MAIN FRAME
14 1 12050-201 SEAT MOUNT
15 1 12050-202 CUSHION BAR
16 1 12050-216 INPUT ARM
17 1 12050-210 CAM
18 1 12050-211 STOP BRACKET
19 1 12050-212 SEAT BACK
20 1 12050-213 DETENT LINK
21 1 12050-343 WASHER
22 1 12050-355 ROTATION DECAL
23 3 12050-368 LINK, SEAT MOUNT
24 2 12050-369 ENDCAP
25 2 12050-370 SPRING, TORSION
26 1 12050-374 DECAL, SEAT ADJUST
27 4 12050-375 PIN, PIVOT
28 1 12050-380 DETENT PLATE
29 1 12050-598-X* PLACARD VR3 LEG EXTENSION
30 1 12050-999-X* OWNER’S MANUAL
31 2 12060-350 WT ROD .625 X 54.63
32 4 12090-322 FOOT PAD
33 1 12100-303 BUMPER
34 1 12101-300 SPACER
35 2 12210-347 GUIDE ROD CAP
36 2 12210-348 GUIDE ROD CAP
37 1 4000Y316-X* DECAL, CAUTION
38 1 4520-362-X* DECAL, CAUTION
39 1 4605-381-X* WARNING LABEL
40 1 4605-511 INSERT,PLASTIC 5.94
41 1 4713-318 PIN,DETENT
42 1 51198 WARRANTY BOOK (NOT SHOWN)
43 4 8500-026* DECAL, CAUTION
44 1 BS070201 COM SPRING .56 x .66 1.50 LG
45 2 BS070208 COMPRESSION SPRING
46 1 CM000211 DECAL, PATENT PENDING
47 2 FB030249 BEARING, RADIAL 35 MM
EXTENDED RACE
48 8 FB130205 BRG,FLG .62 x .75 .38 LG
49 2 FC030009 TOLERANCE RING 72MM
50 87” GB000202 STANDARD WEIGHT STACK
BELT, .95 WIDE
51 2 GP000209 PULLEY ASSEMBLY-3.50
52 2 HC622815 SHCS .250-20 X .750
53 1 HC622820 SHCS .250-20 X 1.25
HC700416 REMOVED 5/28/2010
55 13 HC700417 BHSCS .375-16 X 1.00
56 2 HC700428 BHSCS .375-16 X 2.25
57 3 HC700430 BHSCS .375-16 X 2.50
ITEM QTY PART NO. DESCRIPTION
58 2 HF449063 INSERT 3/4 X 1/4-20
59 12 HF579000 PANEL FASTNER, 10-24 U TYPE
60 1 HH320030 KEY .313 X .313 X 2.50
61 2 HN625200 LOCKNUT, .250-20 NYLON
62 7 HN704901 LOCKNUT, .375-16 NYLON
63 1 HP707017 STUD, .375-16 X 1.00
64 10 HT512517 TAP SC 10-24 X 1.00 TYPE WB PN
HD PHIL BLK
65 12 HX570412 BHSCS, 10-24 X .50, SS
66 2 HY740000 SET SCREW
67 3 JC620422 BHSCS .250-20 x 1.50
68 6 JC700420 BHSCS .375-16 X 1.25
69 1 JC780417 BHSCS .500-13 X 1.00
70 6 JS347400 LOCKWASHER, INT TOOTH .375
71 2 PN660200 INSERT, PLASTIC 1.00 DIA-11 GA
72 2 PP130002 INSERT, DOMED PLASTIC
73 4 PP130003 INSERT, DOMED PLASTIC
74 3 PP660006 PLUG, SNAP IN
75 2 PR060005 BUMPER, WEIGHT
76 2 PR069400 BUMPER, RECESS
77 2 4605-507 GRIP 1.38 OD X .94 ID 2@6.5”
78 1 PU060201 BUMPER
79 1 12050-206 PIVOT SHAFT
80 1 FB030239 CAM FOLLOWER 10mm
81 1 HC700414 BHSCS .375-16 X .625
82 1 12050-345 MOUNT, CAM FOLLOWER
83 1 12050-354 ADJUSTMENT DECAL
84 1 12050-351 PLATE, DECAL CAM
85 1 11050-333 CAM
86 1 11050-407 RETAINER
87 1 11050-408 SPACER
88 1 12050-342 ECCENTRIC PLATE
89 1 12050-377 DECAL,START RLD
90 1 12050-204 CAM PLATE
91 6 JC700924 FHSCS, .375-16 X 1.75
92 1 12050-209 COUNTERWEIGHT MOUNT
93 3 HN704902 LOCKNUT, .375-16 NYLON
94 1 12102-339 STOP GUARD
95 1 12050-207 INPUT ARM
96 1 FB130213 BRG.FLG, 1.375 X 1.625 X .750 LG
97 1 JC620415 BHSCS .250-20 X .75
98 1 12050-205 STOP PLATE
99 1 12050-378 DECAL, TOTAL RLD
100 2 08229 PIN, DETENT
101 2 JC700920 FHSCS .375-16 X 1.25
102 1 HC622817 SHCS .250-20 X 1.00
103 1 12050-353 DECAL, CAM STOP
104 1 12050-322 PLATE, DETENT
105 1 4800-131 SEAT PAD W/WEAR COVER
106 1 4800-134 WEAR COVER
107 1 4800-176 BACK PAD
108 1 4800-006 LEG PAD W/WEAR COVER
109 1 4800-093 WEAR COVER
110 1 12000-466 PULLEY COVER
111 4 HT 570410 PNH TORX 10-24 X .375 BLACK
112 1 PP460011 KNOB, OVAL .375-16 X 1.25 MALE
113 1 4705-332 INSERT, THREADED .375-16X562
114 1 AA033904 V PUSHER
115 1 HM532812 SHCS .138-6-32 X 50 GR 8
116 1 11000-407-X* DECAL, INCREMENT WEIGHT
117 1 13000-402 WATER BOTTLE HOLDER MOUNT
118 1 13000-400 WATER BOTTLE HOLDER
119 1 HT552515 TAP SCREW 8-16 X .75
120 1 11040-790 DECAL, MADE IN U.S.A.
121 1 12100-312 BUMPER
ITEM QTY PART NO. DESCRIPTION
*Language Key
1-German
2-French
3-Spanish
4-English
6- Japanese
7-Swedish
8-Russian
