CapSense Express Controllers Registers TRM, Document No. 001-91082 Rev. *E 29
SENSOR_EN
0x00
1.5.1 SENSOR_EN (continued)
0: Sensor is disabled
1: Sensor is enabled
8 CS8 Capacitive sensor 8 enable. This bit field is not applicable for parts CY8CMBR3102,
CY8CMBR3106S, CY8CMBR3108.
0: Sensor is disabled
1: Sensor is enabled
7 CS7 Capacitive sensor 7 enable. Note that CS7 is SPO1 in part CY8CMBR3108. This bit field is not
applicable for parts CY8CMBR3102, CY8CMBR3106S.
0: Sensor is disabled
1: Sensor is enabled
6 CS6 Capacitive sensor 6 enable. This bit field is not applicable for parts CY8CMBR3102,
CY8CMBR3106S.
0: Sensor is disabled
1: Sensor is enabled
5 CS5 Capacitive sensor 5 enable. Note that CS5 is SPO1 in part CY8CMBR3106S. This bit field is not
applicable for part CY8CMBR3102.
0: Sensor is disabled
1: Sensor is enabled
4 CS4 Capacitive sensor 4 enable. Note that CS4 is SPO0 in part CY8CMBR3110. This bit field is not
applicable for part CY8CMBR3102.
0: Sensor is disabled
1: Sensor is enabled
3 CS3 Capacitive sensor 3 enable. This bit field is not applicable for part CY8CMBR3102.
0: Sensor is disabled
1: Sensor is enabled
2 CS2 Capacitive sensor 2 enable. This bit field is not applicable for part CY8CMBR3102.
0: Sensor is disabled
1: Sensor is enabled
1 CS1 Capacitive sensor 1 enable. Note that CS1 is SPO0 in part CY8CMBR3102.
0: Sensor is disabled
1: Sensor is enabled
0 CS0 Capacitive sensor 0 enable
0: Sensor is disabled
1: Sensor is enabled
