D-FLY DRAGONFLY - Page 9

vii
DFX
Weight: 81lbs / 37kgs
01. Right Front Brake Lever
02. Display
03. Left Rear Brake Lever
04. Mode Selection
05. Accelerator
06. Headlight
07. Battery Lock
08. Battery
09. Motors
10. Rear Light
11. Deck
12. Lights, Horn and Turn Signals
13. Offset
14. Tiller
15. Folding Mechanism
16. Mudguards
17. Handguard / Turn Signals
18. Fender
01
02
03
04
05
06
07
08
09
10
11
12
13
14
15
700
1200 450
1150
16
17
18
