11D-Link DCS-6100LH User Manual
Section 2 - Installation
Twist the screws into the anchors, leaving the top exposed. Do not over-
tighten the screws.
Align the mounting holes on the bottom of the camera with the screws.
Slide the camera down to lock it into place.
4/
5/
4.0 - 4.5 mm
