• IEEE 802.3z compliance
SFP Transceivers Supported:
• DEM-310GT (1000BASE-LX, Single-mode, 10km)
• DEM-311GT (1000BASE-SX, Mutli-mode, 500m)
• DEM-312GT2 (1000BASE-SX, Multi-mode, 2km)
• DEM-314GT (1000BASE-LX, Single-mode, 50km)
• DEM-315GT (1000BASE-LX, Single-mode, 80km)
• DGS-712 (1000BASE-TX)
• DEM-330T/R (1000BASE-BX, WDM transceiver, Single-Mode 10km)
• DEM-331T/R (1000BASE-BX, WDM transceiver, Single-Mode 40km)
• DEM-210 (100BASE-FX, Single-mode, 15km)
• DEM-211 (100BASE-FX, Multi-mode, 2km)
• DEM-220T (100BASE-BX, Wavelength Tx:1550nm, Rx:1310nm, Single-mode,
20km)
• DEM-220R (100BASE-BX, Wavelength Tx:1310nm, Rx:1550nm, Single-mode,
20km
PoE Specifications
• Supports IEEE 802.3af PoE and IEEE 802.3at PoE+ compliance.
• Supplies power to PD devices up to 15.4W per port (802.3af) or 30W+ per port
(802.3at) more sufficiently.
• Power Budget: 370W.
• Supports the Auto Discovery feature. It’ll automatically recognize a connection to
PD devices and immediately provide power.
• Supports the Auto Disable Port feature. If the port’s electrical current is over
600mA, this feature will activate and still keep the other ports active.
• Supports the Active Circuit Protection feature. It’ll automatically disable a port if
there is an electrical short and still keep the other ports active.
Power Classification Table:
Class Usage Max power used by PD
0 Default 12.95W
1 Optional 3.84W
2 Optional 6.49W
3 Optional 12.95W
4 Reserved 12.95W
• For 802.3at capable devices, provide power allocation of 0.1 watt granularity
using LLDP method.
Class Usage Minimum power levels of output of PSE
0 Default 15.4W
1 Optional 4.0W
2 Optional 7.0W
3 Optional 15.4W
4 Reserved 31W
