DIR-825 Quick Installation Guide
Wireless Module Parameters
VHT40
-92dBm at MCS0
-89dBm at MCS1
-87dBm at MCS2
-84dBm at MCS3
-80dBm at MCS4
-76dBm at MCS5
-74dBm at MCS6
-72dBm at MCS7
-68dBm at MCS8
-66dBm at MCS9
VHT80
-89dBm at MCS0
-86dBm at MCS1
-83dBm at MCS2
-80dBm at MCS3
-77dBm at MCS4
-73dBm at MCS5
-71dBm at MCS6
-69dBm at MCS7
-66dBm at MCS8
-64dBm at MCS9
Modulation schemes
· 802.11a: BPSK, QPSK, 16QAM, 64QAM with OFDM
· 802.11b: DQPSK, DBPSK, DSSS, CCK
· 802.11g: BPSK, QPSK, 16QAM, 64QAM with OFDM
· 802.11n: BPSK, QPSK, 16QAM, 64QAM with OFDM
· 802.11ac: BPSK, QPSK, 16QAM, 64QAM, up to
256QAM with OFDM
Physical Parameters
Dimensions (L x W x H)
· 181 x 132.5 x 47.71 mm (7.13 x 5.22 x 1.88 in)
Weight
· 304.8 g (0.67 lb)
Operating Environment
Power
· Output: 12V DC, 1.5A
Temperature
· Operating: from 0 to 40 °C
· Storage: from -20 to 65 °C
Humidity
· Operating: from 10% to 90% (non-condensing)
· Storage: from 5% to 95% (non-condensing)
52
