D-Link DIR Series User Manual

WIRELESS SETTINGS:-
In the wireless network settings give
name to your wireless network,
under wireless security mode select
Enable WPA/WPA2 wireless security
(enhanced), under WPA/WPA2 do
the settings as shown and assign
network key, this will be the
password for your wireless network
and click on save settings.
3)
On next page click on the reboot now
so the new settings will take effect.
4)
To connect wirelessly to your
router, go to the wireless utility on
your laptop. You will able to view
the new network name which you
have assigned.
5)

D-Link DIR Series Specifications

General

Wireless Standard	IEEE 802.11ac
Frequency Band	Dual-band (2.4 GHz and 5 GHz)
Wireless Speed	Up to 1200 Mbps
Ethernet Ports	4 x 10/100/1000 Mbps
WAN Ports	1 x 10/100/1000 Mbps
USB Ports	1 x USB 2.0
Security Protocols	WPA, WPA2, WPA3
Antenna Type	External antennas
