HOW TO ACCESS THE DEVICE:-
Connect the power adapter to the
power socket and other end to the
device and power on the device.
2)
1)
Once the device is powered on,
power LED and the Wi-Fi LED on the
device will be green.
3)
4)
5)
Unbox the device.
Connect one end of the Ethernet
cable provided in to the box into any
of the 4 LAN port of the device at the
back side and connect other end to
the LAN port of your Desktop/Laptop.
Or you can connect to the device
wirelessly. Go to wireless utility of
your laptop. You will be able to view
the available wireless networks. By
Default wireless network name of
the device i.e. SSID is dlink and
there is no password in default
settings. Select the dlink SSID and
say “connect, Kindly see the below
screenshot. After this you will be get
connected to the router.

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the D-Link DIR Series and is the answer not in the manual?

D-Link DIR Series Specifications

General IconGeneral
Wireless StandardIEEE 802.11ac
Frequency BandDual-band (2.4 GHz and 5 GHz)
Wireless SpeedUp to 1200 Mbps
Ethernet Ports4 x 10/100/1000 Mbps
WAN Ports1 x 10/100/1000 Mbps
USB Ports1 x USB 2.0
Security ProtocolsWPA, WPA2, WPA3
Antenna TypeExternal antennas
