8
Connect XT60 Port
200W Solar Panel
Connection with Solar Panel
MC4 Connection
Connect XT60 Port
200W Solar Panel (x2)
Connection with Solar Panel
MC4 Connection
When charging the product with a Dabbsson solar panel, follow the instructions of this user
manual to avoid damage to the product.
You can fully charge the product with AC+PV total 1400W Max input in 1.7 hours.
AC+PV Charging
400W Max Solar Panel
AC 1000W
MC4 Connection
