Installation
English20
Installation
01
04
04
03
05
1110
06
02 02
08
07
09
01 2" (50 mm)
02 135°
03 64” (1624 mm)
04 14
1
/8" (358 mm)
05 35
3
/4" (908 mm)
06 24" (610 mm)
07 2
1
/2" (64 mm)
08 4
1
/8" (104 mm)
09 1
3
/4" (45.4 mm)
10 43
1
/8" (1095.5 mm)
11 45" (1143 mm)
NOTE
The measurements in the table above may differ slightly from the actual measurements,
depending on the measuring and rounding method.
