English 25
Installation
Detach the Fresh Zone drawer
1. Lift up to remove the Fresh Zone
basket.
2. Remove the wire cover with harness
using a at-head screwdriver.
3. Press the locking tab to disconnect the
wire connector.
4. Remove the hex-head bolt from each
side using a socket wrench (
3
/8", 10 mm)
or a screwdriver.
DACOR_RF8000MC_DA68-03563J-00_EN.indd 25 2017-03-09  11:32:28
