21. Keep the pneumatic system interior or the engine
interior from the infiltration of dust.
22. Install the gasket mounted in the contact surface of
each case of the engine while removing gasket materi-
al completely. Remove damaged contact surface by
wiping with the oil stone equally.
23. Pay attention not to bend the cable excessively.
Transformed or damaged cable may cause malfunction
or damage.
24. Install the boots with the installing groove by inserting
the boots into the groove.
BOOTS
SERVICE INFORMATION

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the DAELIM S3 and is the answer not in the manual?

DAELIM S3 Specifications

General IconGeneral
Fuel SystemCarburetor
Transmission5-speed
Front SuspensionTelescopic Fork
Front BrakeDisc
Rear BrakeDrum
Seat Height780 mm
Engine4-stroke
Engine Type4-stroke
Rear SuspensionDual shock
Fuel Tank Capacity12.5 L
