317L 317R 316L 317R
128 IC SWITCHING 1BA7755A-- BA7755A (HEAD SW) 1 1 1 1 IC602
129 JACK ANTENNA 9736322200 T-646 1 1 1 1 J001
130 JACK HEADPHONE 9766319501 HTJ-064-05B GOLD 1 1 1 1 J801
131 JACK RCA 9CD6313700 S-436P 1 1 1 1 J401
132 JACK SPEAKER 9736320500 CJ-9007-040 1 1 1 1 J802
133 LED DLTL307EE- LTL-307EE(RED)PI5 - 1 - 1 LD713
134 PIN WAFER 9736407700 52084-1310 13P BOTTOM 1 1 1 1 CW 401
135 PIN WRAPPING 9713550400 1.0X2.5X15 6 6 6 6
TP501 TP502 TP503 TP504 TP901
TP902
136 R CARBON FILM RD-2Y229J- 1/2 2.2 OHM J 1 1 1 1 R550
137 R CARBON FILM RD-4Z100J- 1/4 10 OHM J 2 2 2 2 R588 R589
138 R CARBON FILM RD-4Z102J- 1/4 1K OHM J 4 4 4 4 R815 R816 R817 R818
139 R CARBON FILM RD-4Z479J- 1/4 4.7 OHM J 2 2 2 2 R809 R810
140 R CARBON FILM RD-AZ100J- 1/6 10 OHM J 7 7 7 7
R004 R009 R206 R255 R545
R720 R921
141 R CARBON FILM RD-AZ101J- 1/6 100 OHM J 15 15 15 15
R008 R102 R227 R228 R301
R304 R313 R436 R437 R546
R654 R663 R664 R672 R719
142 R CARBON FILM RD-AZ102J- 1/6 1K OHM J 41 41 41 41
R208 R215 R216 R251 R256
R260 R261 R262 R263 R323
R409 R410 R423 R424 R431
R432 R511 R521 R522 R563
R564 R580 R601 R602 R603
R604 R613 R614 R647 R648
R659 R734 R736 R737 R739
R740 R744 R746 R74
143 R CARBON FILM RD-AZ103J- 1/6 10K OHM J 38 40 36 38
L208 R213 R214 R254 R257
R258 [R276 R277] R579 R619
R620 R624 R639 R640 R641
R642 [R701 R702 R704 R707]
[R705 R708] R709 R711 [R712]
[R713]R714 R715 R716 R721
R722 [R727 R730] R733 R735
R738 [R747] R754 R757 R7
144 R CARBON FILM RD-AZ104J- 1/6 100K OHM J 26 26 26 26
R109 R421 R422 R425 R426
R433 R434 R439 R440 R443
R445 R502 R510 R518 R519
R548 R549 R567 R568 R584
R585 R671 R762 R764 R823
R824
145 R CARBON FILM RD-AZ105J- 1/6 1M OHM J 6 6 6 6
R505 R508 R559 R560 R622
R665
146 R CARBON FILM RD-AZ106J- 1/6 10M OHM J 1 1 1 1 R717[R759]
147 R CARBON FILM RD-AZ109J- 1/6 1 OHM J 2 2 2 2 R939 R940
148 R CARBON FILM RD-AZ121J- 1/6 120 OHM J 1 1 1 1 R551
149 R CARBON FILM RD-AZ122J- 1/6 1.2K OHM J 2 2 2 2 R405 R406
150 R CARBON FILM RD-AZ123J- 1/6 12K OHM J 10 10 10 10
R259 R509 R523 R531 R532
R533 R538 R539 R557 R558
151 R CARBON FILM RD-AZ124J- 1/6 120K OHM J 1 1 1 1 R513
152 R CARBON FILM RD-AZ151J- 1/6 150 OHM J 5 5 5 5 R302 R305 R314 R627 R628
153 R CARBON FILM RD-AZ152J- 1/6 1.5K OHM J 4 4 3 3 R325 R778 R779 R780
154 R CARBON FILM RD-AZ153J- 1/6 15K OHM J 10 10 11 11
[R371] R403 R404 R411 R412
R515 R553 R554 R643 R644
R822
155 R CARBON FILM RD-AZ154J- 1/6 150K OHM J 3 3 3 3 R503 R525 R821
156 R CARBON FILM RD-AZ181J- 1/6 180 OHM J 3 3 2 3
R303 R306 R315 [R353
R362 R780]
157 R CARBON FILM RD-AZ182J- 1/6 1.8K OHM J 3 3 3 3 R413 R414 [R741 R733]
158 R CARBON FILM RD-AZ183J- 1/6 18K OHM J 5 5 5 5 R201 R203 R526 R813 R814
159 R CARBON FILM RD-AZ184J- 1/6 180K OHM J 6 6 6 6
R504 R625 R626 R637 R638
R651
160 R CARBON FILM RD-AZ220J- 1/6 22 OHM J 1 1 1 1 R534
161 R CARBON FILM RD-AZ221J- 1/6 220 OHM J 4 4 4 4 R441 R552 R933 R934
162 R CARBON FILM RD-AZ222J- 1/6 2.2K OHM J 10 10 10 10
R211 R212 R253 R264 R407
R408 [R737 R740] R581 R742
R747
163 R CARBON FILM RD-AZ223J- 1/6 22K OHM J 7 7 7 7
R107 R528 R530 R615 R616
[R724] R753 R911
164 R CARBON FILM RD-AZ224J- 1/6 220K OHM J 3 3 3 3 R629 R630 R726
165 R CARBON FILM RD-AZ271J- 1/6 270 OHM J 2 2 2 2 R307 R316 [R354 R363]
166 R CARBON FILM RD-AZ272J- 1/6 2.7K OHM J 8 8 8 8
R222 R223 R427 R428 R611
R612 R617 R618
167 R CARBON FILM RD-AZ273J- 1/6 27K OHM J 3 3 3 3 R542 R555 R556
168 R CARBON FILM RD-AZ331J- 1/6 330 OHM J 4 4 4 4
R007 [R308 R317] [ R355
R364] R670
NO Parts Name
Parts Code Description
Q'ty
Location
