Note 1)
1 Neither indoor unit nor outdoor unit runs.
Check the following points first. (There are following case in normal operation)
a. Is the timer mode set the "timer ON".
b. Is the timer mode set the "timer-OFF" and the time had passed?
2 Neither outdoor fan nor compressor runs while indoor fan runs.
Check following points first. (There are following cases in normal operation)
a. Is the temperature set point suitable?
b. Has the 3 minutes time guard for compressor operated?
Function Descriptions
ITEM DESCRIPTIONS REMARK
Cooling - Desired Temperature Range: 18°C~32°C
Cooling
- Operating after the I/D Fan Moter is run for 20 minutes
at Auto Mode
* Cooling condition: In case of “Desired temp. +3°C
<Room temp.”
- Desired Temperature Range: 24°C~28°C
Cooling Cooling - Desired Temperature Range: Fixed on 18°C
at Quick Mode - I/D Fan level: Fixed on “HIGH”
- COMP ON: In case of “Room temp.
< Desired temp.-1°C”
COMP, O/D FAN - COMP OFF: In case of “Room temp.
> Desired temp +1°C”
- O/D Fan: ON or OFF with COMP. (Operate same timing)
- I/D Fan level: Fixed on “LOW”
- There are three types of sub-operation
1) In case of “Room temp.
> Desied temp.+1°C”
COMP, O/D Fan: Continuously ON
I/D Fan level: Fixed on “LOW”
Dehumidify 2) In case of “Desired temp. -1°C
≤ Room temp. ≤ Desired temp. +1°C”
COMP, O/D Fan: 3minutes ON, 5minutes OFF
Dehumidify I/D Fan level: Fixed on “LOW”
3) Room temp.
< Desired temp.-1°C
COMP, O/D Fan: Continuously OFF
I/D Fan level: Fixed on “LOW”
- Operating after the I/D Fan Moter is run for 20 minutes
* Dehumidify condition: In case of “Desired temp.-2°C
≤ Room temp.
≤ Desired temp.+3°C”
- Desired Temperature Range: 24°C~28°C
Mode Change Operation Mode Auto → Quick → Cooling → Fan → Dehumidify → Auto → Roation
Auto Mode and Cooling Mode: Auto → Low → Mid → High → Natural
Fan Moed: Low → Mid → High → Natural
I/D Fan control Fan level set * Natural: Veriable pattern operation “Mid → Low → Mid → High → “
* Auto: Operating according to the difference of Room temp. and
Desired temp.
Sleep Mode Desired temp. control
- Increase the desired temp. 0.5°C every 30 minutes and then the unit
automatically turn off after 4hours
Reservation Mode Timer - On or OFF timer operation: In can be set 30 minutes from to 12 hours
Dehumidify
at Auto Mode
