DAEWOO ELECTRONICS DSA-240L-R - Part Lists; Indoor Unit Part List

54
No PART CODE PART NAME Q'TY SPEC REMARK
1 3100400600 BODY 1 DSB-240L-R/LH-R
2 3108007500 MOTOR FCU 1 IC-9430DWKG7A
3 3101500400 CUSHION MOTOR 2 CR I.D30 (R/W45)
4 3106400200 BEARING PLASTIC ASSY 2 O.D37 .0*I.D6.0
5 3100076400 FAN CROSS FLOW ASSY 1 Ø100XL864
6 7485401012 SET SCREW 1 6S-4*10-E MFZN(BLACK)
7 3103003800 HOLDER MOTOR L/B 1 DSB-240L-R/LH-R
8 3103003900 HOLDER MOTOR R 1 DSB-240L-R/LH-R
9 3103004000 HOLDER BEARING 1 ABS T2.5
10 7172401211 SCREW TAPPING 3 TT2 TRS 4*12 MFZN
11 3100089100 EVAPORATOR 1 ASSY
12 3104440100 PIPE ARTRON HOSE 1 O.D:42 I.D:26 T=7, F-PE
13 7172401211 SCREW TAPPING 1 TT2 TRS 4*12 MFZN
14 3108101400 PAN DRAIN 1 DSB-240L-R/LH-R
15 3106502700 BLADE VERTICAL (M) 2.5 DSB-240L-R/LH-R J360A
16 7141400811 SCREW TAPPING 1 T2 PAN 4X8 MFZN
17 3107600500 FLAP UP 2 DSB-240L-R/LH-R
18 3107600600 FLAP DOWN 1 DSB-240L-R/LH-R
19 3107801700 LINK FLAP 1 DSB-240L-R/LH-R
20 3100702000 BUSHING 2 DSB-240L-R/LH-R
21 3103200800 HOSE DRAIN ASSY 1 ASSY
22 3108007600 MOTOR STEPPING 1 GSP-24RW-062
23 3104301700 LED PCB ASSY 1 18/24K (150X24.5X1.6T)
24 7112300611 SCREW TAPPING 2 T1, TRS M3
*
6
25 3106002900 WASHER PLASTIC 2 IS Ø3
26 3100077000 CONTROL BOX ASSY 1 ASSY
27 3100510700 BOX CONTROL 1 DSB-240L-R/LH-R
28 3101200400 CLAMP POWER CORD 1 DA-5N
29 7172401211 SCREW TAPPING 2 TT2 TRS 4
*
12 MFZN
30 3101300440 POWER CORD ASSY 1 SJT 3X14 AWG105
31 3104300830 CONTROL PCB ASSY 1 240LH-R(A), 240LH-R(B)
* DSA-240L/LH PART LIST (INDOOR UNIT)
✔ Caution: In this Service Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the
latest parts information, please refer to PPL(Parts Price List) in Service information Center(http://svc.dwe.co.kr)
