No PART CODE PART NAME Q'TY SPEC REMARK
1 3100041750 BASE PAN PAINT ASSY 1 PAINTING
2 310P30281A FOOT CUSHION 4 NBR (54
*
63.5)
3 3100068201 COMPRESSOR ASSY 1 AWG5530EXC
4 7400208411 WASHER PLAIN 3 ID8.4
*
OD22
*
T1.6
5 7392801211 NUT LOCK 3 M8
*
1.25P
6 3100078000 CONDENSER ASSY 1 AL+CU DSB-240LH-R
7 3100082900 PIPE CAPILLARY ASSY 1 C1220T H/P
8 3100082800 PIPE REVERSING ASSY 1 C1220T-O
9 3102402100 GRILLE COND 1 PE
10 3100041100 GUIDE POST P/T ASSY 1 PAINTING
11 3100041201 BRK SERVICE P/T AS 1 PAINTING
12 3105401800 SERVICE VALVE (G) 1 Ø15.88 (5/8”)
13 3105401200 SERVICE VALVE (L) 1 Ø9.52 (3/8”)
14 3106002300 BOLT HEX 4 M6
*
L20 MFZN
15 3100031702 PLT PARTITION ASSY 1 SGCC-M-Z22
16 3100088500 ASSY PANEL CONTROL 1 SGCC-M-Z22 T0.8 H/P
16-1 3104201601 PANEL CONTROL 1 SGCC-M-Z22 T0.8
16-2 3108912330 TERMINAL BOLCK 1 SN-DBW-6P
16-3 3101202000 CLAMP CORD 1 NYLON66, (VDE)
16-4 3109508100 CAPACITOR DUAL 1 5/45MF 400VAC
16-5 3101203300 CLAMP CAPACITOR 1 SGCC Ø63 T0.8
16-6 5SC0202700 POWER RELAY 1 G7L-2A-TUB, 220/240V 50/60H
17 3105300400 SUPPORT MOTOR 1 SGCC-M-Z22 T1.6
18 3108007400 MOTOR ODU 1 OSME986DERC 230/50
19 7348602011 BOLT HEX 4 WAS M6*L20 MFZN
20 3101802000 FAN PROPELLER 1 ABS+G/F(20%)
21 3100031400 CABINET FRONT P/T AS 1 PAINTING
22 3100031500 CABINET SIDE P/T AS 1 PAINTING
23 3100041500 PANEL TOP P/T ASSY 1 PAINTING
24 3102102000 GRILLE DISCHARGE 1 (BE-002D)
25 3100044250 SERVICE COVER ASSY 1 ASA
