EXPLODE VIEW AND PARTS LIST
E01 CABINET 3610811101 D-F's 1
E02 FRAME TOP *L 36122UDY00 SGCC 1.2T, FT1081 1
E03 FRAME TOP *R 36122UDZ00 SGCC 1.2T, FT1081 1
E04 FRAME LOWER 36122WD500 SGCC T1.0 1
E05 BASE UNDER *L 3610395000 SGCC T1.6 100X500 1
E06 BASE UNDER *R 3610395100 SGCC T1.6 1
E07 FRAME UPPER 36122UE000 SGCC 1.0T, FT1081 1
E08 LEG ADJUST AS 3617703811 CHINA PARTS, DWD-900W 4
E09 COVER BACK AS 361142552T COVER BACK+CUSHION 1
E10 EMI FILTER 3611908820 DPC D-FT1081 2X0.47UP(X2), 1
2X1500PF(Y2),BODY CHANGE
E11 UNIT DRAIN PUMP AS 3618980000 D-H's PUMP,LELLI,220~240V, 1
35W ,DPH5 ,WIRE TYPE
E12 STOPPER SPRING 3615202200 POM, DWD-100DR 2
E13 HOSE DRAIN *O 3613268210
L=1800 HOSE+CUFF(ST) D-MU80
1
E14 CLAMP HOSE 3611206410 NYLON, DA-16N, ID21.9 D-MU80 1
E15 SCREW TAPPING 7122401411 T2S TRS 4X14 MFZN 1
E16 CLAMP HOSE 3611204701 DI=26 1
E17 HARNESS AS 3612796200 D-HT'S,HOT,BUBBLE(C.PUMP) 1
E18 CAP WATER REMAIN 3610916800 PP 1
E19 HOSE WATER REMAIN 3613268700 EPDM,ID=8.5, L200 1
No. PART NAME PART CODE SPECIFICATION Q'TY REMARK
