14
NO. PART NAME PART CODE DESCRIPTION Q'TY SVC REMARK
F01 DUCT_B_AS 36171-0006500-00 220V, ALCOSTA, GF+PET, MINI-II 1 Y COMBO
F02 DUCT_B_LOWER_AS 36171-0006200-00 DUCT *B SEAMING JIG 1 Y COMBO
F03 DUCT_B_LOWER 36171-0005900-00 ALCOSTA 0.6T MINI-II COMBO 1 Y COMBO
F04 HEATER_DRY 66127-0002200-00
220V 1050W, TERMINAL ANGLE 90,
INCOLOY800
1 Y COMBO
F05 SCREW_TAPPING 7122400811 T2S TRS 4X14 MFZN 3 Y COMBO
F06 SCREW_TAPPING 7122401011 T2S TRS 4*10 MFZN 1 Y COMBO
F07 COVER_DUCT 36113-0032200-00 ALCOSTA 0.6T MINI-II COMBO 1 Y COMBO
F08 GASKET_SEAL 36123-0009601-00 EPDM FOAM, 3TX8X380, MINI-II 1 Y COMBO
F09 GASKET_SEAL 36123-0009701-00 EPDM FOAM, 3TX8X165, MINI-II 1 Y COMBO
F10 GASKET_SEAL 36123-0009900-00 EPDM FOAM, 3TX8X25, MINI-II 1 Y COMBO
F11 SWITCH_THERMOSTAT 66148-0006100-00
SWITCH THERMOSTAT, PACIFIC CONTROLS,
115℃/130℃, MINI 2.0
1 Y COMBO
F12 SCREW_TAPPING 7122401011 T2S TRS 4*10 MFZN 2 Y COMBO
F13 HARNESS SUB 66126-0022602-00
UL1015 AWG18 90MM #250 FLAG, HEATER
DRY-THERMOSTAT
1 Y COMBO
F14 FUSE-TEMPERATURE 66122-0000501-00
FUSE TEMPERATURE, 141℃, DONGYANG, 15A
250V, MINI 2.0, 400MM
1 Y COMBO
F15 SUPPORTER_FUSE 36147-0006300-00 SBHG 16X16.9X8.8 1.0T EURASIA COMBO 1 Y COMBO
F16 SCREW_TAPPING 7122401011 T2S TRS 4*10 MFZN 1 Y COMBO
F17 GASKET_SEAL 36123-009101-00 High density EPDM FOAM, 5TX12X140, MINI-II 1 Y COMBO
F18 COVER_FAN 36113-0032300-00 PA66+GF30% MINI-II COMBO 1 Y COMBO
F19 UNIT_FAN_MOTOR_AS 66149-0008606-00
FAN MOTOR, NAKAGAWA, DR7806SSWC/W
17.5VDC, 1700RPM, 1.6A,CCW
1 Y COMBO
F20 SCREW_TAPPING 7122401011 T2S TRS 4*10 MFZN 3 Y COMBO
F21 BUSHING_SHAFT 36107-0000800-00 PC T=0.2, DO=17, DI=8 EURASIA COMBO 1 Y COMBO
F22 SEAL_FAN 36189-0001400-00
NBR HS50 DI7.4 H5.2-6.5 EURASIA COMBO
BLACK
1 Y COMBO
F23 FAN_AS_ASM ASSY F18+F19+F20+F21+F22+F24+F25+F26+F27+F28 1 Y COMBO
F24 FAN_AS 36117-0001100-00 PA66+GF30% MINI-II COMBO 1 Y COMBO
F25
GASKET_SEAL_
SILICONE
36123-0008900-00 SILICON, 6.5X4X200, MINI-II 1 Y COMBO
F26 NUT_HEX 90003-0005200-00 NI-ZN PLATED M6*1 CW 1 Y COMBO
F27
GASKET_SEAL_
SILICONE
36123-0008800-00 SILICON, 6.5X4X530, COVER FAN, MINI-II 1 Y COMBO
F28 GASKET_SEAL_EPDM 36123-0009000-00 EPDM FOAM, 10TX12X110, MINI-II 1 Y COMBO
F29 SCREW TAPPING 7122401011 T2S TRS 4*10 MFZN 8 Y COMBO
F30 DUCT_GUIDE_SUB_AS ASSY F31+F32+F33+F34+F35+F36+F37+F38+F39+F40 1 Y COMBO
F31 DUCT_GUIDE_UPPER 36171-0006000-00 PA66+GF30% MINI-II COMBO 1 Y COMBO
F32 DUCT_GUIDE_LOWER 36171-0006100-00 PA66+GF30% MINI-II COMBO 1 Y COMBO
F33
PACKING_DUCT_
GUIDE
36137-0023000-00 SILICONE MINI-II COMBO 1 Y COMBO
F34 SCREW TAPPING 7122401411 T2S TRS 4X14 MFZN 2 Y COMBO
F35 PROTECTOR_DUCT 36185-0006000-00 SGCC 0.5T, MINI-II 1 Y COMBO
F36 SCREW_TAPPING 7122401011 T2S TRS 4*10 MFZN 2 Y COMBO
F37 PACKING-THEMISTOR 36137-0022900-00 SILICON MINI-II COMBO 1 Y COMBO
F38 THERMISTOR_DRY 361AAAAC00 R40=26.065kΩ,R90=4.4278kΩ 1 Y COMBO
MINI 2.0_COMBO,WASH_영문_SM.indd 14 2017. 8. 25. 오전 11:16
