DAEWOO ELECTRONICS MINI - Parts and Components

5
2. Specifications
1. Parts and Components
NO Parts
1 TUB REAR
2 BODY
3 DOOR FRAME * O
4 DOOR PROTECTOR
Category
Specifications
Notes
COMBO WASH
Dimension
NET 550 x 650 x 324 550 x 600 x 324
GROSS 615 x 712 x 399 615 x 658 x 395
Weight
NET 19.8 17.32
GROSS 23.04 21.28
Standard Volume 27L 26L
Power 220V/50Hz 220V/50Hz
Power
Consumption
Wash 100W 100W
Wash Heater(230V) 1300W 1300W
Dry 1100W -
Max Load
Wash 3.0kg 3.0kg
Spin 1.5kg -
Washer Type Front Load
Installation Mounted on Wall
Water Pressure 98.1kPa~784kPa(1kgf/cm²~8kgf/cm²)
1
1
2
2
3
3
4
4
NO Parts
1 TUB REAR
2 BODY
3 DOOR FRAME * O
4 DOOR PROTECTOR
WASHER
COMBO
