ҧThe quantities or locations of switches could be different from the figure, because the switches could be added or
omitted, or locations could be changed by the requirements of customers.
LEGEND OF INSTRUMENT PANEL AND OTHER DEVICES
No. Description No. Description No. Description
1 Voltage meter
2
Engine coolant temperature gauge
3 Fuel gauge–Engine
4 Engine oil pressure
5 Air pressure gauge
6 Upper pilot lamps
7 Engine RPM gauge
8 Lower pilot lamps
9 Tachograph (OPTION)
Speedometer (OPTION)
10 Door opening switch (FRT)
11 Door opening switch(MID) (OPT)
12 Microphone stand
13 Radio & Cassette player
14 Switches
15 Door opening switch(RR) (OPT)
17 Defroster controller
18 Engine idling knob
19 Shift lever
(Except auto transmission)
20 Accelerator pedal
21 Wiper control and exhaust
brake lever
22 Brake pedal
23 Horn switch
24 Bulb check
25 Steering wheel
26 Head & Direction lamp lever
27 Clutch pedal
28 Valve–cab control
29 Clutch oil reservoir
30 Control panel (OPTION)
31 Door controller
32 Cup holder (BM090, BS106)
