25
Voltmeter
The voltmeter indicates the battery
condition. Check the voltmeter read-
ing with the engine running. The
gauge needle should stand between
the reading of 24 and 28.
Temperature gauge
The gauge indicates the engine
coolant temperature. If the gauge
needle stands below the red colored
zone, it means that engine coolant
temperature is normal.
If the needle stands in “H”(overheat-
ing), stop the vehicle and run the
engine at a moderately fast idle
speed or put the gear in lower posi-
tion to reduce engine load. If the
vehicle is operated in abnormal con-
dition, engine performance will be
reduced and fuel consumption will be
increased.
Fuel gauge
This gauge indicates fuel level of the
fuel tank all the time regardless of the
starter switch position.
The capital letter “E” represents
almost “empty”. Top–up the fuel tank
before the gauge indicates “E”.
