-26-
SERVICE PARTS LIST
N002 4857417500 TERM PIN DA-IB0214(D2.3/DY PIN)
N003 4857417500 TERM PIN DA-IB0214(D2.3/DY PIN)
N004 4857417500 TERM PIN DA-IB0214(D2.3/DY PIN)
N005 4857417500 TERM PIN DA-IB0214(D2.3/DY PIN)
N006 4857417500 TERM PIN DA-IB0214(D2.3/DY PIN)
P402 485923512S CONN WAFER YW025-08 (STICK)
P403 485923162S CONN WAFER YW025-03 (STICK)
P803 485923522S CONN WAFER YW025-09 (STICK)
R302 RS01Z331J- R M-OXIDE FILM 1W 330 OHM J (TAPPING)
R305 RS02Z471JS R M-OXIDE FILM 2W 470 OHM J SMALL
R306 RS02Z471JS R M-OXIDE FILM 2W 470 OHM J SMALL
R307 RS01Z129J- R M-OXIDE FILM 1W 1.2 OHM J (TAPPING)
R401 RS02Z101JS R M-OXIDE FILM 2W 100 OHM J SMALL
R402 RS02Z150JS R M-OXIDE FILM 2W 15 OHM J SMALL
R403 RS01Z369J- R M-OXIDE FILM 1W 3.6 OHM J (TAPPING)
R404 RS01Z229J- R M-OXIDE FILM 1W 2.2 OHM J (TAPPING)
R407 RS02Z109JS R M-OXIDE FILM 2W 1 OHM J SMALL
R414 RS01Z562J- R M-OXIDE FILM 1W 5.6K OHM J (TAPPING)
R417 RS02Z101JS R M-OXIDE FILM 2W 100 OHM J SMALL
R453 RS01Z229J- R M-OXIDE FILM 1W 2.2 OHM J (TAPPING)
R807 RS02Z228JS R M-OXIDE FILM 2W 0.22 OHM J SMALL
R820 RS02Z109JS R M-OXIDE FILM 2W 1 OHM J SMALL
R836 RS02Z473JS R M-OXIDE FILM 2W 47K OHM J SMALL
R841 RS02Z473JS R M-OXIDE FILM 2W 47K OHM J SMALL
R905 RS02Z153JS R M-OXIDE FILM 2W 15K OHM J SMALL
R906 RS02Z153JS R M-OXIDE FILM 2W 15K OHM J SMALL
R907 RS02Z153JS R M-OXIDE FILM 2W 15K OHM J SMALL
ZZ200 PTPWJRH611 PCB POWER RADIAL AS DVQ-10H1FCN
C301 CEXF1H479V C ELECTRO 50V RSS 4.7MF (5X11) TP
C302 CEXF1V101V C ELECTRO 35V RSS 100MF (8X11.5) TP
C303 CXSL2H100D C CERA 500V SL 10PF D (TAPPING)
C304 CMXM2A103J C MYLAR 100V 0.01MF J (TP)
C305 CMXM2A104J C MYLAR 100V 0.1MF J (TP)
C309 CEXD1H229Q C ELECTRO 50V RT 2.2MF (6.3X11) TP
C310 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11) TP
C405 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11) TP
C409 CMXM2A104J C MYLAR 100V 0.1MF J (TP)
C412 CMXM2A103J C MYLAR 100V 0.01MF J (TP)
C413 CCXB2H102K C CERA 500V B 1000PF K (TAPPING)
C415 CEXF2C109V C ELECTRO 160V RSS 1MF (6.3X11) TP
C452 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11) TP
C802 CCXB2H222K C CERA 500V B 2200PF K (TAPPING)
C803 CCXB2H222K C CERA 500V B 2200PF K (TAPPING)
C809 CMXM2A332J C MYLAR 100V 3300PF J (TP)
C811 CMXM2A473J C MYLAR 100V 0.047MF J (TP)
C812 CEXF1H229V C ELECTRO 50V RSS 2.2MF (5X11) TP
C820 CCXB3A471K C CERA 1KV B 470PF K (T)
C822 CEXF2A100V C ELECTRO 100V RSS 10MF (6.3X11) TP
C825 CEXF1C101V C ELECTRO 16V RSS 100MF (6.3X11) TP
C826 CEXF1H479A C ELECTRO 50V RSM 4.7MF 4X7
C827 CEXF1C221V C ELECTRO 16V RSS 220MF (8X11.5) TP
C828 CEXF2A100V C ELECTRO 100V RSS 10MF (6.3X11) TP
C830 CCXB3A471K C CERA 1KV B 470PF K (T)
C831 CCXB3A471K C CERA 1KV B 470PF K (T)
LOC PART CODE PART NAME DESCRIPTION REMARK
C832 CCXB3A471K C CERA 1KV B 470PF K (T)
C834 CMXM2A104J C MYLAR 100V 0.1MF J (TP)
C835 CEXF1C470V C ELECTRO 16V RSS 47MF (5X11) TP
C836 CEXF1H479V C ELECTRO 50V RSS 4.7MF (5X11) TP
C853 CMXM2A102J C MYLAR 100V 1000PF J (TP)
C854 CMXM2A102J C MYLAR 100V 1000PF J (TP)
C855 CCXB3A471K C CERA 1KV B 470PF K (T)
C857 CMXM2A102J C MYLAR 100V 1000PF J (TP)
C858 CMXM2A103J C MYLAR 100V 0.01MF J (TP)
C859 CMXM2A102J C MYLAR 100V 1000PF J (TP)
F801A 4857415001 CLIP FUSE PFC5000-0702
F801B 4857415001 CLIP FUSE PFC5000-0702
I806 1KA431L--- IC KA431L
L823 58C9430599 COIL CHOKE AZ-9004Y(94MH)
L824 58C9430599 COIL CHOKE AZ-9004Y(94MH)
L901 5CPX121J-- COIL PEAKING 120UH J (RADIAL)
Q401 TKTC3207-- TR KTC3207 (TP)
Q451 TKTA1266Y- TR KTA1266Y (TP)
Q802 TKTC3198Y- TR KTC3198Y
Q803 TKTC3198Y- TR KTC3198Y
Q804 TKTC3198Y- TR KTC3198Y
Q805 TKTC3198Y- TR KTC3198Y
Q820 TKSA1013Y- TR KSA1013Y (TP)
Q821 TKSA1013Y- TR KSA1013Y (TP)
Q823 TKSA1013Y- TR KSA1013Y (TP)
Q824 TKTC3198Y- TR KTC3198Y
Q825 TKTC3198Y- TR KTC3198Y
Q826 TKTC3198Y- TR KTC3198Y
Q852 TKTC3198Y- TR KTC3198Y
Q853 TKTA1270Y- TR KTA1270Y (TP)
Q901 TKTC3207-- TR KTC3207 (TP)
Q902 TKTC3207-- TR KTC3207 (TP)
Q903 TKTC3207-- TR KTC3207 (TP)
ZZ200 PTPWJAH611 PCB POWER AXIAL AS DVQ-10H1FCN
A001 4859808660 PCB UNION 246X246 S1B
C806 CCZB1H223K C CERA HIBK 50V 0.022MF K AXL 52
C807 CBZF1H104Z C CERA SEMI 50V F 0.1MF Z
C808 CCZB1H221K C CERA 50V B 220PF K (AXIAL)
C810 CBZF1H104Z C CERA SEMI 50V F 0.1MF Z
C813 CCZB1H222K C CERA 50V B 2200PF K AXIAL
C901 CCZB1H271K C CERA 50V B 270PF K
C902 CCZB1H271K C CERA 50V B 270PF K
C903 CCZB1H271K C CERA 50V B 270PF K
D301 D1N4004S-- DIODE 1N4004S
D302 DUZ33B---- DIODE ZENER UZ-33B
D303 DUZ33B---- DIODE ZENER UZ-33B
D401 D1N4937G-- DIODE 1N4937G (TAPPING)
D402 D1N4937G-- DIODE 1N4937G (TAPPING)
D403 D1N4937G-- DIODE 1N4937G (TAPPING)
D404 D1N4937G-- DIODE 1N4937G (TAPPING)
D405 DUZ9R1BM-- DIODE ZENER UZ-9.1BM
D406 D1N4937G-- DIODE 1N4937G (TAPPING)
D451 D1N4937G-- DIODE 1N4937G (TAPPING)
D452 D1N4148--- DIODE 1N4148 (TAPPING)
LOC PART CODE PART NAME DESCRIPTION REMARK
