Daewoo DVQ-10H1FCN User Manual

-27-
SERVICE PARTS LIST
D453 D1N4937G-- DIODE 1N4937G (TAPPING)
D801 DLT2A05G-- DIODE LT2A05G (TP)
D802 DLT2A05G-- DIODE LT2A05G (TP)
D803 DLT2A05G-- DIODE LT2A05G (TP)
D804 DLT2A05G-- DIODE LT2A05G (TP)
D805 D1N4148--- DIODE 1N4148 (TAPPING)
D806 D1N4148--- DIODE 1N4148 (TAPPING)
D807 D1N4148--- DIODE 1N4148 (TAPPING)
D808 D1N4148--- DIODE 1N4148 (TAPPING)
D809 D1N4148--- DIODE 1N4148 (TAPPING)
D810 DUZ6R2BM-- DIODE ZENER UZ-6.2BM
D820 DRGP15J--- DIODE RGP15J
D821 D1N4937G-- DIODE 1N4937G (TAPPING)
D823 DRGP15J--- DIODE RGP15J
D824 DUZ9R1BM-- DIODE ZENER UZ-9.1BM
D825 DRZ1175V1- DIODE ZENER RZ1175V1
D827 DUZ15BM--- DIODE ZENER UZ-15BM
D853 DRGP15J--- DIODE RGP15J
D854 D1N4937G-- DIODE 1N4937G (TAPPING)
D856 DRGP15J--- DIODE RGP15J
J001 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J002 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J003 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J004 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J005 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J006 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J007 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J008 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J009 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J010 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J011 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J012 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J013 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J014 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J015 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J016 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J017 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J018 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J019 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J020 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J021 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J022 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J023 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J024 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J025 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J026 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J027 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J028 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J029 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J030 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J031 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J032 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
L401 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
L802 5MC0000100 COIL BEAD HC-3550
LOC PART CODE PART NAME DESCRIPTION REMARK
L803 5MC0000100 COIL BEAD HC-3550
L820 5MC0000100 COIL BEAD HC-3550
L851 5MC0000100 COIL BEAD HC-3550
L852 5MC0000100 COIL BEAD HC-3550
L853 5MC0000100 COIL BEAD HC-3550
L854 5MC0000100 COIL BEAD HC-3550
R301 RD-AZ682J- R CARBON FILM 1/6 6.8K OHM J
R308 RD-AZ273J- R CARBON FILM 1/6 27K OHM J
R309 RD-AZ222J- R CARBON FILM 1/6 2.2K OHM J
R310 RD-AZ333J- R CARBON FILM 1/6 33K OHM J
R311 RD-AZ113J- R CARBON FILM 1/6 11K OHM J
R312 RN-4Z1502F R METAL FILM 1/4 15K OHM F
R313 RN-4Z1603F R METAL FILM 1/4 160K OHM F
R320 RD-AZ103J- R CARBON FILM 1/6 10K OHM J
R405 RD-AZ153J- R CARBON FILM 1/6 15K OHM J
R406 RD-AZ113J- R CARBON FILM 1/6 11K OHM J
R408 RD-4Z224J- R CARBON FILM 1/4 220K OHM J
R409 RD-4Z472J- R CARBON FILM 1/4 4.7K OHM J
R410 RD-2Z751J- R CARBON FILM 1/2 750 OHM J
R411 RD-AZ331J- R CARBON FILM 1/6 330 OHM J
R412 RD-AZ102J- R CARBON FILM 1/6 1K OHM J
R451 RD-4Z224J- R CARBON FILM 1/4 220K OHM J
R452 RD-AZ472J- R CARBON FILM 1/6 4.7K OHM J
R454 RD-4Z224J- R CARBON FILM 1/4 220K OHM J
R455 RD-AZ102J- R CARBON FILM 1/6 1K OHM J
R456 RD-AZ103J- R CARBON FILM 1/6 10K OHM J
R457 RD-AZ103J- R CARBON FILM 1/6 10K OHM J
R803 RD-4Z394J- R CARBON FILM 1/4 390K OHM J
R804 RD-4Z394J- R CARBON FILM 1/4 390K OHM J
R805 RD-4Z333J- R CARBON FILM 1/4 33K OHM J
R806 RD-4Z432J- R CARBON FILM 1/4 4.3K OHM J
R808 RD-AZ331J- R CARBON FILM 1/6 330 OHM J
R809 RD-AZ330J- R CARBON FILM 1/6 33 OHM J
R810 RD-AZ331J- R CARBON FILM 1/6 330 OHM J
R811 RD-AZ331J- R CARBON FILM 1/6 330 OHM J
R812 RD-AZ102J- R CARBON FILM 1/6 1K OHM J
R813 RD-AZ222J- R CARBON FILM 1/6 2.2K OHM J
R814 RD-AZ471J- R CARBON FILM 1/6 470 OHM J
R815 RD-AZ102J- R CARBON FILM 1/6 1K OHM J
R816 RD-AZ560J- R CARBON FILM 1/6 56 OHM J
R817 RD-AZ204J- R CARBON FILM 1/6 200K OHM J
R818 RD-AZ204J- R CARBON FILM 1/6 200K OHM J
R819 RD-AZ472J- R CARBON FILM 1/6 4.7K OHM J
R821 RD-4Z363J- R CARBON FILM 1/4 36K OHM J
R822 RD-AZ363J- R CARBON FILM 1/6 36K OHM J
R823 RD-AZ363J- R CARBON FILM 1/6 36K OHM J
R824 RD-AZ104J- R CARBON FILM 1/6 100K OHM J
R825 RD-AZ104J- R CARBON FILM 1/6 100K OHM J
R826 RD-AZ392J- R CARBON FILM 1/6 3.9K OHM J
R827 RN-AZ2001F R METAL FILM 1/6 2.0K OHM F
R828 RD-AZ473J- R CARBON FILM 1/6 47K OHM J
R829 RD-AZ304J- R CARBON FILM 1/6 300K OHM J
R830 RD-AZ103J- R CARBON FILM 1/6 10K OHM J
R831 RD-AZ472J- R CARBON FILM 1/6 4.7K OHM J
LOC PART CODE PART NAME DESCRIPTION REMARK
