Daewoo DWR-WE6413RC - Electrical Connection Options

19
Review the following options to determine the appropriate electrical connection for your home:
Use the instructions in this section if your home has a
4-wire receptacle (NEMA type 14-30R) and you will be
using a UL listed, 120/240 volt minimum, 30 amp,
dryer power supply cord.
Use the instructions in this section if your home has a
3-wire receptacle (NEMA type 10-30R) and you will be
using a UL listed, 120/240 volt minimum, 30 amp,
dryer power supply cord.
4-wire receptacle
(NEMA type14-30R)
3-wire receptacle
(NEMA type10-30R)
If this type is available at your home. you will be
connecting to a fused disconnect or circuit breaker
box.
If this type is available at your home. you will be
connecting to a fused disconnect or circuit breaker
box.
4-wire direct
3-wire direct
