2. Parts list
NO PART CODE PART NAME DESCRIPTION QUANTITY REMARK
1 ASSY URT CAB 1
2 4018G57110 GUIDE DRN *O 1
3 HEATER GLAS AS 1 REFER TO # 9
4 4019R73570 COVER DEFR HTR *T AL 1
5 4019R73580 COVER DEFR HTR *U AL 1
6 4019R03205 EVAPORATOR AS 1
7 3018100603 SWITCH BIMTL AS 1
8 4017Z90590 FUSE TEMP AS 1
9 4017Z90590 FIXTURE FUSE TEMP PP 1
10 3012900401 HINGE *U AS MF-ZN5-C 1
11 3016000600 SPECIAL SCREW M6 X20 4
12 3010023400 SWITCH DR AS 1
13 4017Z40622 FOOT *F ASS 2
14 3010302300 BASE COMP 1
15 4019H09010 ABSORBER COMP NR-A 4
16 COMPRESSOR 1 REFER TO # 8
17 3014503802 PLATE AXCON AS 1
18 4019H09030 SPECIAL WASHER SWRH 4
19 SWITCH P RELAY AS 1 REFER TO # 8
20 DRYER AS 1 REFER TO # 9
21 401ZA26000 DAMPR R ASS 1
22 4010C31261 INSULATOR DAMP A F-PS 1
23 4017Z31272 INSULATOR DAMP B F-PS 1
24 4017G32670 GEAR ABS 1
25 4017Z18180 KNOB ABS 1
26 LAMP AS 1 REFER TO # 9
27 400EL19311 SOCKET LAMP AS 200, 200/WHITE HOUSING 1
28 4010R21300 DAMPER AS D-702-1 1
29 4010R22131 COVER DAMP HIPS 1
30 4017Z87570 SHADE R HC-2 1
31 4010C75260 SEAL MULTI DUCT 1
32 4010C75270 SEAL MULTI DUCT B 1
33 4010R75220 INSU MULTI DUCT 1
34 4010R75213 DUCT MULTI HIPS 1
35 4010C75252 LABEL DUCT PC T0.17 1
36 FAN MOTOR ASS 1
37 4017Z42312 FAN ABS 1
38 MOTOR SHADED AS 1 REFER TO # 9
39 3010502401 BOX CONTL AS 1
ā Caution :
In this Service Manual, some parts can be changed for improving, their performance without notice in the parts list.
So, if you need the latest parts information, please refer to PPL (Parts Price List) in Service Information Center
(http://svc.dwe.co.kr)
To Next Page
