NO PART CORD PART NAME DESCRIPTION Q'TY REMARK
1 3620401700 BODY AS ASS’Y, METALLIC 1 L
3620402200 ASS’Y D, E
3620403910 ASS’Y SEMKO
2 3620003600 MOTOR AS 100V/1200W 1 L
3620003700 220V/1200W D, E
3620003900 230V/1200W
3620005300 230V/1200W SEMKO
3 3629503100 CORD REEL AS JIS 6m 1 110V
3629503150 JIS 5m, 110~127V 110~127V
3629502001 KS 5m, 220~2400 220~240V
3629504100 70565,5m, SEMKO SEMKO
4 3621901610 BAG FILTER CLOTH BAG 1 D, E
4560A57001 PAPER BAG L
5 3621406800 COVER AS ASS’Y, METALLIC 1 L
3621407800 ASS’Y D, E
3621411700 ASS’Y SEMKO
6 7121402011 SCREW TAPPING T2S PAN 4X20 4
7 3626601400 BUTTON CR ABS 1
8 3625103000 SPRING HSW3 1
9 3621408100 COVER NOZZLE ABS 1
10 3628100100 NOZZLE CREVICE PP+NYLON 1 L
3628100300 PP D, E
11 3629300100
BRUSH DUSTING AS
ABS+NYLON 1 L
3629301500 ABS+NYLON D, E
12 3624303400 PCB AS 110V/50~60HZ 1
3624303500 220~240V/50HZ
3624303510 230V/50HZ SEMKO
3624303600 220~240V/60HZ
13 3623202800 HOSE AS SWING BUTTON 200KΩ 1 L
3623202300 BUTTON 200KΩ
3623202310 BUTTON 500KΩ
3623203310 SWING INSERT 500KΩ 1.8m D, E
3623203400 SWING INSERT 500KΩ 1.5m
14 3624404600 PIPE AS BLOWER, INSERT 1 E
3624404500 STEEL, INSERT
3624400610 BUTTON L
3624400710 BUTTON+HOLDER
15 3629301600
SUCTION BRUSH AS
EUROPEAN 1 E
3629301700 EUROPEAN, BUTTON
3629301410 QUIET, BUTTON L
3629302000 QUIET D
✔ Caution:
In this Service Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the
latest parts information, please refer to PPL(Parts Price List) in Service information Center(http://svc.dwe.co.kr)
