Daewoo RC-705 - Page 17

16
BODY ASSEMBLY :
NO PART CORD PART NAME DESCRIPTION Q'TY REMARK
1 3620401600 BODY ABS 1
2 3620600100 BRACKET ROLLER PA 1
3 3624700210 ROLLER PA+TPE 1
4 3624701100 ROLLER ABS+TPE 2
5 3622000100 FIXTURE ROLLER ABS+CR 2
6 3621408200 COVER ROLLER ABS 2 3626402200
3621401400 3620401700
7 7121401611 SCREW TAPPING T2S PAN 4X16 MFZN 6
8 3628300500 PROTECTOR TPE 1
9 3629800300 SOCKET ABS 1
10 3624002000 PACKING SOCKET CR 1
11 7121401411 SCREW TAPPING T2S PAN 4X14 2
12 3620703900 TERMINAL AS TERMINAL+WIRE 1
13 3623002000 HOLDER FILTER ABS 1
14 3625102700 SPRING HSW3 1
15 3621801100 FILTER PE NOWOVEN MAT 1
16 3621101300 CASE FILTER ABS 1
17 3624000100 PACKING CASE CR FOAM 1
18 3620102700 ABSORBER VIBRATION CR FOAM 1
19 3621901200 FILTER PP FIBER 1
20 3622400300 GRILLE ABS 1
21 3622400200 GRILLE ABS 1
22 3629000200 SWITCH MICRO AS MICRO S/W+WIRE 1
23 3622501000 GUIDE GRILLE ABS 1
24 3625103100 SPRING HSW3 2
25 3626000200 SPECIAL WASHER SPCC 2
26 7121400811 SCREW TAPPING T2S PAN 4X8 2
27 3622000300 FIXTURE FILTER ABS 2
28 3620104200 ABSORBER SOUND PU FOAM T=10 1
29 3620103100 ABSORBER SOUND PE-FOAM 2
30 3620103200 ABSORBER SOUND FELT T=0.5 1
31 4560F24030 PACKING HOLE PE-FOAM 2
32 3620103300 ABSORBER SOUND FELT T=0.5 1
✔ Caution: In this Service Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the
latest parts information, please refer to PPL(Parts Price List) in Service information Center(http://svc.dwe.co.kr)
