18
NO PART CORD PART NAME DESCRIPTION Q'TY REMARK
1 3621405800 COVER DUST ABS 1 D
3621407900 L
2 3621200800 CLAMP COVER ABS 1 D
3621201200 L
3 3621202800 SPRING HSW 1 D
3621205800 L
4 3625500500 WINDOW DM PE FILM+UV 1
5 3629700400 DUST METER AS ASSY 1
6 3621406000 COVER DM ABS 1
7 7121401411 SCREW TAPPING T2S PAN 4X14 2
8 3621408000 COVER RODY ABS 1 D
3621405700 L
9 4519F35000 LATCH PUSH LA701 KIFCO 1
10 3620102800
ABOSRBER VIBRATION
CR FOAM 1
11 3624002100 PACKING HOLE EVA FOAM 2
12 3620103700
ABSORBER SOUND
FELT T=5.0 1
COVER ASSEMBLY : 3621407800/3621406800
✔ Caution:
In this Service Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the
latest parts information, please refer to PPL(Parts Price List) in Service information Center(http://svc.dwe.co.kr)
