NO PART CORD PART NAME DESCRIPTION Q'TY REMARK
1 3962330320 MOTOR 220V, 1200W O/S HARNES 1
3962330520 220V, 1200W O/S HARNES
3620003700
3962230300 110V, 1200W O/S HARNES
3620003600
3962510220 230V, 1200W O/S HARNES
3620003900
3962610400 240V, 1200W O/S HARNES
3962511200 2300 1200W DMI (F)
3620005300
2 3624000900 PACKING MOTOR CR FOAM 1
3 3621101100 CASE MOTOR ABS 1
4 3621901300 FILTER PU FOAM T=10 1
5 3622500700 GUIDE AIR ABS 1
3622500710 PC
6 3620103400 ABSORBER SOUND FELT T=3.0 2
7 3627900100 MOUNT MOTOR TPE (O/S) 1
3627900300 CR (DMI)
8 7171401411 SCREW TAPPING T2S PAN 4X14 1
9 3621101200 CASE MOTOR ABS 1
MOTOR ASSEMBLY :
✔ Caution:
In this Service Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the
latest parts information, please refer to PPL(Parts Price List) in Service information Center(http://svc.dwe.co.kr)
To Next Page
