CORD REEL ASSEMBLY :
NO PART CORD PART NAME DESCRIPTION Q'TY REMARK
1 3629200100 BOBBIN ABS 1
2 3628700100 TERMINAL C2600P T=0.5 1
3 3628700200 TERMINAL C2600P T=0.5 1 4D
4 3621300501 CORD POWER 250V7A WO-SIN 6.3M 1 2L
4560F38020 125V 12A
3629503150
3621300101 250V WO-SIN 5M
3629502001
4569A36010 300 AC/15A
3629504100
5 3629200200 BOBBIN ABS 1
6 7121401211 SCREW TAPPING T2S PAN 4X12 3
7 3624900500 SHAFT REEL ABS 1
8 3625102000 SPRING AS SU301+COVER 1
9 7121300811 SCREW TAPPING T2S PAN 3X8 2
10 3620600400 BRACKET CR ABS 1
11 3628701900 TERMINAL AS Y TER+WH+RECEP 1
12 3623703700 TERMINAL AS Y TER+WH+RECEP 1
13 3623700900 LEVER CR ABS 1
14 3625103200 SPRING HSW3 1
15 4569C35082 STOPPER CR NBR 1
16 4565A35070 FRAME STOPPER POM 1
17 7121400811 SCREW TAPPING T2S PAN 4X8 2
18 7121400211 SCREW TAPPING T2S PAN 4X12 1
19 3622705000 HARNESS HOUSING+RECEP+WIRE 1
20 4569B47002 THERMOSTAT PW2 T85 1
21 7121300611 SCREW TAPPING T2S PAN 3X6 1
22 4505A63041 CEC ST CE550 1
23 7121300611 SCREW TAPPING T2S PAN 3X6 1
✔ Caution:
In this Service Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the
latest parts information, please refer to PPL(Parts Price List) in Service information Center(http://svc.dwe.co.kr)
