NO PART CORD PART NAME DESCRIPTION Q'TY REMARK
1 3629100300 ADAPTER ABS 1
2 3625102900 SPRING HSW3 1
3 3628704200 TERMINAL C280W-H 2
4 3621200900 CLAMP ADAPTER ABS 1
5 3621405900 COVER ADAPTER ABS 1
6 7121300811 SCREW TAPPING T2S PAN 3X8 1
7 3623201600 HOSE PVC-S/SWRS 1
8 8YS20018YW WIRE LED VSF 20/0.18 2
9 4560F77000 HOOK HOSE PP 1
10 2193101100 SOLDER BAR SNA 60:40 0.00
11 2TU00019BK TAPE VINYL 19MM BLACK 0.5
12 4565A70040 COVER HOSE PP 2
13 3624400400 PIPE HOSE ABS 1
14 3625100600 SPRING HSW3 1
15 3626600200 BUTTON PIPE POM 1
16 5V2204003B VR SLIDE(CUTING) VJ3013-2PVN 200K 1
3623202300
5V2504005B VJ3013-2PVN 500K 1
3623202310
17 3624301410
PCB SLIDE VOLUME
66X16 1.6T 1
19 7121300811 SCREW TAPPING T2S PAN 3X8 2
20 3623400100 KNOB PC 1
21 3621401310 COVER PIPE ABS METALLIC 1
3623202310
3621401300
3623202300
22 7121301211 SCREW TAPPING T2S PAN 3X12 2
23 8YS20018YW WIRE LEAD VSF 20/0.18 0.5
24 3624500200 PLATE ABS 1
✔ Caution:
In this Service Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the
latest parts information, please refer to PPL(Parts Price List) in Service information Center(http://svc.dwe.co.kr)
