28
NO PART CORD PART NAME DESCRIPTION Q'TY REMARK
1 3629100300 ADAPTER ABS 1
3623203400
3629500310 PC
3623203310
2 3625102900 SPRING HSW3 1
3 3628703800 TERMINAL AS TERMINAL+WIRE 2
4 3621200900 CLAMP ADAPTER ABS 1
5 3621405900 COVER ADAPTER ABS 1
6 7121300811 SCREW TAPPING T2S PAN 3X8 1
7 3623202900 HOSE PVC-S/SWRS 1.5m 1
8 2TU00019BK TAPE VINYL 19MM BLACK 0.5
9 4565A70040 COVER HOSE PP 2
10 3629100400 ADAPTER PIPE ABS 1
11 3622200700
FRAME TERMINAL AS
FRAME+TERMINAL AS 1
12 3622200600 FRAME TERMINAL ABS 1
13 3624002400 PACKING PIPE NBR 1
14 2291140301 WAX SILICON TSC987 1 CAN-200G
15 3624403800 PIPE HOSE ABS 1
16 3628704600 TERMINAL AS TERMINAL+WIRE+RECE 2
17 3621409000 COVER TERMINAL ABS 1
18 7121301011 SCREW TAPPING T2S PAN 3X10 1
19 3624303900
PCB SLIDE VOLUME AS
PCB+S/V+HOUSING 1
20 7121300800 SCREW TAPPING T2S PAN 3X8 2
21 3624500200 PLATE ABS 1
22 3623400100 KNOB PC 1
23 3621409700 COVER PIPE ABS 1
24 7121301211 SCREW TAPPING T2S PAN 3X12 2
✔ Caution:
In this Service Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the
latest parts information, please refer to PPL(Parts Price List) in Service information Center(http://svc.dwe.co.kr)
