30
NO PART CORD PART NAME DESCRIPTION Q'TY REMARK
1 3624402000 PIPE BRUSH PP 1
3629301600
3624402400
3629301700
2 3628000700 NECK PP 1
3 3623100100 HOOK PA 2
4 3621405400 COVER BRUSH PP 1
5 3621406200 COVER AIR PP 1
6 3624900400 SHAFT SWRM+MFZN 1
7 3624701000 ROLLER PA+TPE 2
8 7402004011 RING E ER-4 MFZN 2
9 3620901500 CAP ROLLER PA 2
10 3623700800 LEVER BRUSH ABS 1
11 3624500800 PLATE BRUSH AS ASSY 1
12 3625102600 SPRING HSW3 2
13 3624700600 ROLLER PA+TPE 2
14 3628200200 PIN SWRM MFZN 2
15 3624500600 PLATE BRUSH SUS T=0.5 1
16 3627000100 PICKER LITTER ABS+NYLON 2
17 7121401411 SCREW TAPPING T2S PAN 4X14 MFZN 4
18 3621405500 COVER PIPE PP 1
19 7121300812 SCREW TAPPING T2S PAN 3X8 MFZN 1
✔ Caution:
In this Service Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the
latest parts information, please refer to PPL(Parts Price List) in Service information Center(http://svc.dwe.co.kr)
