PIPE ASSEMBLY: I
NO PART CORD PART NAME DESCRIPTION Q'TY REMARK
1 3621402820 COVER PIPE ABS METALLIC 1
3624400620
3621402800 ABS
3624400610
2 3626600200 BUTTON PIPE POM 1
3 3625100500 SPRING HSW3 1
4 3624401700 PIPE ABS 1
PIPE ASSEMBLY :
NO PART CORD PART NAME DESCRIPTION Q'TY REMARK
1 3621402820 COVER PIPE ABS METALLIC 1
3624400710
3621402800 ABS
3624400720
2 3626600200 BUTTON PIPE POM 1
3 3625100500 SPRING HSW3 1
4 3624401700 PIPE ABS 1
5 3623000500 HOLDER ABS 1
3624400720
3623002400
3624400710
6 7121401411 SCREW TAPPING T2S PAN 4X14 1
✔ Caution:
In this Service Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the
latest parts information, please refer to PPL(Parts Price List) in Service information Center(http://svc.dwe.co.kr)
