Daewoo RC-705 - 6-9-3. Extension Pipe Assembly: 3624404500

36
6-9-3) EXTENSION PIPE ASSEMBLY : 3624404500
1
1
4
2 3
NO. PART CODE PART NAME DESCRIPTION Q'TY REMARK
1 3624403500 PIPE STEEL HDPE+SPC 2
2 3623001900 HOLDER PIPE ABS 1
3 2625000400 SPACER EVA POAM T=1.5 1
4 7121401411 SCREW TAPPING T
2
S PAN 4X14 MFZN 1
✔ Caution: In this Service Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the
latest parts information, please refer to PPL(Parts Price List) in Service information Center(http://svc.dwe.co.kr)
