Daewoo RC-705 User Manual

3. WIRING DIAGRAM
4
THERMOSTAT
CORD REEL
MOTOR
MICRO S/W
P. C. B
SLIDE VOLUME
BLUE
BLACK
WHITE
BLUE
BLACK
WHITE
WHITE
WHITE
MOTOR
THERMO
STAT
N85°C
POWER CORD
AC 230V / 50Hz
POWER
C3
C2
FILTER COIL
TRIAC
R5
R4
R3
P.C.B (SN : 3624303450)
C1
DIAC
YELLOW
YELLOW
R1 R2
12uH
8A
12uH
8A
11 12
G
MICRO
SWITCH
S / V
500K
PART NAME
R1, R2
R3
R4
R5
TRIAC
DIAC
C1, C2, C3
FILTER
COIL
S / V
(SLIDE VOLUME)
MOTOR
MICRO
SWITCH
10K OHM, 1/2W
180K OHM, 1/2W
240K OHM, 1/2W
100 OHM, 1W
600V, 5A
37V~40V, DB4
AC 600V, 0.1uF
120uH, 12A
500K OHM
250V, 3A
VH1120A020
SPEC
CIRCUIT DIAGRAM

Daewoo RC-705 Specifications

General

Brand	Daewoo
Model	RC-705
Category	Vacuum Cleaner
Language	English
