14
REFRIGERATOR LEVELING &
DOOR ADJUSTMENT
The refrigerator must be level in order to maintain optimal
performance and desirable front appearance.
refrigerator doors look unbalanced.)
Leveling Refrigerator
1. Pull open the freezer compartment and remove the upper
drawer and lower drawer basket to gain access.
2. Using the wrench provided, turn the leveling leg clockwise
to lower and counterclockwise to raise the front corners of
the refrigerator.
3. Install the lower drawer basket and upper drawer, then
open and close the freezer compartment several times to
make sure operation is smooth and without hindrance.
Adjusting a refrigerator door
If the height of the refrigerator doors is uneven, turn the screw nut
on the middle hinge to adjust the refrigerator door.
1. To raise a refrigerator door turn the screw
counterclockwise.
2. To lower a refrigerator door turn the screw clockwise.
If the freezer drawer is lower on one side than the other,
perform the steps listed below to raise that side. To access
extension. then remove the pullout drawer and the freezer
basket.
1. Loosen the four screws on the rail bracket on the side
where adjustment is needed.
2. Unscrew and remove Stopper and at washers from the
lower position (left picture). Insert washers and screw
Stopper into the upper position (right picture). The stopper
Knob to adjust the height of the rail bracket.
3.
a different position, then release the knob back into place.
The knob surfaces push against the edge of the stopper
ring to vary the height of the rail bracket. The maximum
adjustment variance is approximately 1/8 inch.
4. Retighten the four rail bracket screws.
5. Reinsert the freezer basket and pullout drawer.
When inserting the basket, make sure that the tabs at the
rails.
REFRIGERATOR INSTALLATION
1
3
2
1
2
3
