TP-501G Part List
No. Item Code Description Qty Unit Location
8 024-CSB455E CERAMIC RESONATOR CSB455E 1
p
c
9 073-CD100-01 RUBBER KEYS (4-KEYS:
STOP/PLAY/DOWN/UP) CD100
1pc
10 078-PR99-03 Battery Plate |+| PR99/100 1
p
c
11 078-PR99-05B Battery Contact |+,-| PR99/100 1
p
c
12 081-PA 176 Screw P1.7x6A 2
p
cs 2/REMOTE
13 081-PA 24 Screw P2x4A 1
p
c 1/REMOTE
14 081-PA 38 Screw P3x8A 1
p
c 1/FOR REMOTE HEAD
15 082-UL70BK Jumper Wire (UL1571#28) 70mm Black 1
p
c 1/BATT (-)
16 082-UL70R Jumper Wire (UL1571#28) 70mm Red 1
p
c 1/BATT (+)
17 087-0PR99-01 Battery Spring |-| PR99/100 1
p
c
No. Item Code Description Qty Unit Location
1 001-CD155-0U7 P.C.B CD155 REMOTE CD KEY-4
|AVID| PT222 2 BONDING IC REV-0
1pc
2 002-02222-M23 I.C. PT2222 DICE REMOTE CTRL 1
p
cU1
No. Item Code Description Qty Unit Location
1 001-BCX125A-0BT P.C.B BCX125A BATT+RM+PH S-
SIDE BOARD REV-0
1pc
2 028-025 AC SOCKET COVER FOR |VDE| 1
p
c
3 028-AC203S AC SOCKET AC203 (SEIKO) AC-001 1
p
c
4 036-0036-UL03AW-2 3 Pin Wire 200mm UL2547#28 (Hx1)
GREY CD-36
1pc
1/錄放板到卡式機芯
5 036-BC125-UL04W-
P2
4 PIN WIRE 240MMx2 160mmx2
UL1007#26 HX1 P=2MM BCX125A
1pc
1/主板與卡式機芯
6 040-BCX125A ANTENNA ROD L=552MM
BCX125A-501
1pc
Model No : TP-501G Page : 1
Part No : BCM138AR-A401 Status : MP(量產)
Description : RMX0101B REMOTE CD (NOR) 4 KEYS PT2222 IC Verified Date : 01/18/2006
32
Description : RMX0101B REMOTE CD (BONDING) 4 KEYS Verified Date : 01/18/2006
Model No : TP-501G Page : 1
Part No : BCM138AR-A402 Status : MP(量產)
Description : MECHANISM 120V ST (全球線路) METAL GRILL Verified Date : 01/18/2006
Model No : TP-501G Page : 1
Part No : BCM138A-B004 Status : MP(量產)
