Daewoo TP-605GUC - FM Performance Specifications

PAGE: 3 OF 7
FM PERFORMANCE SPECIFICATIONS
No. Test Items Unit Nominal Limit Remark1
1 Intermediate frequency MHz 10.7 +/-0.1
2 Tuning range MHz 87.35-108.35 +/-0.35
3 Dial calibration 90MHz KHz
106MHz KHz
90KHZ uV
4 MAX SENS 98MHz uV
106MHz uV
30 dB quieting 90MHz uV 10 20
5 98MHz uV 10 20
sensitivity 106MHz uV 10 20
6 IF rejection 90MHz dB 50 45
7 Image rejection 106MHz dB 25 20
8 S/N ratio1mV input 22.5 KHz dev dB 40 35
9 3 dB limiting sensitivity uV 10 20
10 T.H.D 22.5 KHz dev % 0.65 1.5
11 AM suppression dB 32 26
12 Modulation hum100mv 22.5KHz dev dB 40 35
13 AFC hold rang - 3 dB l mV KHz 300 200~400
14 Frequency response -3dB Hz 60 100
KHz 5 3.5
15 Overload break mV
16 Output power 32 KHz dev 1mV W
17 10% THD power 75KHz dev. 1mV W 2 1.8
18 Hum & Noise level mV 3 5
19 Spurious response dB
20 Muting on level uV
21 Muting bandwidth KHz
22 Alternate channel selectivity 0.1 mV
input +/- KHz dB
23 Capture ration 1mV dB
24 FAIL OUTPUT VOLTAGE (DC) V
SEEK SENSITIVITY db
