DAF CF 2017 User Manual

20
1
Quick Reference Guide
Heat and ventilation control panel (CCP)
1Display
2 Rotary switch (desired
temperature setting and/or
(timer) adjustment
3 Increasing the fan speed
4 Soft key to activate the timer or
go back one step in the settings
(timer not available on vehicles
equipped with ADR or SLP)
5 Air distribution to upper outlet
openings ('C' in the air
distribution overview)
6 Air distribution to the middle air
vents ('A' in the air distribution
overview)
7 Air distribution to the bottom
outlet openings ('B' in the air
distribution overview)
8 'AUTO' mode on /off
9 Decreasing the fan speed
10 Air conditioning on / off
11 Auxiliary heater
12 De-fog mode
13 Recirculation mode
14 Soft key to activate rest heat or,
if activated by soft key (4), for
timer settings
D005206
13 14 1 2 3 4 5
1112 10 9 8 7 6
DW63299401.book Page 20 Monday, September 4, 2017 3:58 PM
